| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 01. | 9746511 | [1] | PIPE | |
| 10. | 4174542 | [1] | PLUG | |
| 10A. | 4506424 | [1] | O-RING | |
| 13. | 4190127 | [2] | CLAMP;PIPE | |
| 14. | J011265 | [2] | BOLT;SEMS | |
| 57. | 4286917 | [2] | TEE;S | |
| 57A. | 4506424 | [1] | O-RING | |
| 58. | 4042033 | [3] | ADAPTER | |
| 58A. | 4506424 | [1] | O-RING | |
| 59. | 4065118 | [1] | ELBOW;S | |
| 59A. | 4506424 | [1] | O-RING | |
| 60. | 4368690 | [1] | HOSE | |
| 61. | 4368691 | [1] | HOSE | |
| 62. | 4368692 | [1] | HOSE | |
| 63. | 4368693 | [1] | HOSE | |
| 65. | 4044420 | [3] | PROTECTOR |
