神钢零件查询(65R5P) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (14-015) - TRANSMISSION OPTIONAL TOOL (7904-) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
796 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-6. | VAMH061304 | [1] | PULLER AND INSTALLER T/M BEARING (M0 ONLY) | |
| 1. | VA0372681012 | [1] | CLAW, COUNTER SHAFT BEARING (M0 ONLY) | |
| 1. | VAMH061305 | [1] | CLAW, MAIN SHAFT BEARING (M0 ONLY) | |
| 2. | VAMH061306 | [1] | PROTECTOR (M0 ONLY) | |
| 3. | VAMH061307 | [1] | BODY (M0 ONLY) | |
| 4. | VAMH061309 | [1] | ROD, BEARING PULLER (M0 ONLY) | |
| 4. | VAMH061308 | [1] | ROD, BEARING PULLER (M0 ONLY) | |
| 5. | VA0372681016 | [1] | BOLT (M0 ONLY) | |
| 6. | VA0372681017 | [1] | PLUG (M0 ONLY) | |
| 7. | VAMH061321 | [1] | PULLER, COMPANION (M0 ONLY) | |
| 8. | VAMH061301 | [1] | PULLER; 4TH & O/D SYNCHRO, HUB (M0 ONLY) | |
| 9. | VAMH061317 | [1] | BEARING, DRIVE PINION (M0 ONLY) | |
| 10. | VAMH061320 | [1] | RETAINER,DUMMY (M0 ONLY) | |
| 11. | VAMH061302 | [1] | INSTALLER, OILSEAL FR (M0 ONLY) | |
| 12. | VAMH061318 | [1] | BEARING,COUNTER DUMMY (M0 ONLY) | |
| 13. | VAMH061303 | [1] | INSTALLER, OIL SEAL FR (M0 ONLY) | |
| 14. | VAMH061322 | [1] | GUIDE,OIL SEAL (M0 ONLY) | |
| 15. | VAMH061002 | [1] | EXPANDER, SNAP RING (M0 ONLY) | |
