神钢零件查询(BOOM) - ATTACHMENT, (2 PIECE) - SK70SR-1E & SK70SR-1ES ASN YT04-07001 (1/04-12/12) (02-005) - BOOM MAIN GROUP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
281 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02B00012F1 | [1] | BOOM GROUP | |
| 1. | 2444R1117D070 | [1] | HOSE,6.40mm ID x 700mm L | KOB700mm Long (27-1/2 in) |
| 2. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 3. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 4. | 2445R138D3 | [2] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| 5. | YT02B01046P1 | [1] | SUPPORT | KOBSUPPORT |
