神钢零件查询(BOOM) - ATTACHMENT, (2 PIECE) - SK70SR-1E & SK70SR-1ES ASN YT04-07001 (1/04-12/12) (02-008) - HYDR LINES, BOOM FRONT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
888 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT42H00013F1 | [1] | HYD LINES, BOOM | |
| 1. | YT42H01042P1 | [2] | TUBE | KOBTUBE |
| 2. | YT42H01068D2 | [2] | HOSE | KOBHOSE |
| 3. | ZC26X22011 | [4] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 4. | ZS18C10045 | [4] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 5. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 6. | YT30H01012P1 | [3] | GROMMET | KOB |
| 7. | PY01P01043D8 | [3] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
