神钢零件查询(BOOM) - ATTACHMENT, (2 PIECE) - SK70SR-1E & SK70SR-1ES ASN YT04-07001 (1/04-12/12) (02-009) - CYLINDER INSTAL Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
599 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02B00015F1 | [1] | CYLINDER INSTAL | |
| 1. | YT02B01017P1 | [1] | PIN | KOBPIN |
| 2. | YT02B01006P1 | [1] | PIN | KOB Superseded by part number: YR02B01298P1 |
| 3. | HS18C12125G2 | [1] | SCREW | KOBM12x1.75x125mm |
| 4. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 5. | 2418T21137 | [1] | WASHER | KOB |
| 6. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 7. | ZN18C12010 | [2] | NUT | KOBM12x1.75mm |
| 8. | YT02B01008D1 | [1] | SHIM,0.5mm Thk | KOB(0.5) |
| 9. | B16T0442D93 | [1] | SHIM,120mm OD x 72mm ID x 0.9mm Thk | KOBID 72 x OD 120 x Th 0.9mm |
| 10. | YT02B01008D2 | [1] | SHIM,1.2mm Thk | KOB(1.2) |
| 11. | YR02B01262P1 | [2] | SHIM,2.0mm Thk | KOB(2.0) |
| 12. | B16T0442D82 | [1] | SHIM,120mm OD x 77mm ID x 0.5mm Thk | KOBID 77 x OD 120 x Th 0.5mm |
| 13. | B16T0442D81 | [1] | SHIM,120mm OD x 77mm ID x 0.9mm Thk | KOBID 77 x OD 120 x Th 0.9mm |
| 14. | B16T0442D80 | [1] | SHIM,120mm OD x 77mm ID x 1.2mm Thk | KOBID 77 x OD 120 x Th 1.2mm |
| 15. | YR02B01261P1 | [2] | SHIM,2mm Thk | KOB(2.0) |
