神钢零件查询(BOOM) - ATTACHMENT, (2-PIECE BOOM) SK135SR-1E, SK135SRLC-1E, SK135SRLC-1ES (11/01-12/10) (06-017[01]) - UPPER HARNESS ASSEMBLY, (2-PIECE BOOM), (YY13E00009F6), PAGE 1 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
503 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YX13E01006D1 | [1] | CABLE | KOB |
| 2. | 2486R89D5 | [1] | CABLE | KOB |
| 3. | YN13E01053D3 | [1] | CABLE | KOB350mm Long (13-49/64 in) |
| 4. | YX13E01020D1 | [1] | CABLE | KOB |
| 6. | LE13E01006P1 | [1] | HARNESS | KOB100mm Long (3-15/16 in) |
| 7. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 8. | ZW26X08000 | [3] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 11. | YX13E01015P1 | [1] | GROMMET | KOB |
| 12. | YX13E01012P1 | [1] | GROMMET | KOB |
| 13. | PY13E01039P1 | [1] | RUBBER | KOB |
| 16. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 17. | YX13E01016P1 | [1] | GROMMET | KOB |
| 19. | YY13E01071P1 | [1] | WIRE HARNESS | KOBHarness |
| 21. | ZS18C08016 | [3] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 24. | YY13E01072P1 | [1] | HARNESS | KOB |
| 25. | YY13E01054P4 | [1] | HARNESS | KOB |
