斗山零件查询OIL COOLER PIPING(2) SOLAR 220LC-6 Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
771 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
2400-1768B
|
[-] |
OIL COOLER PIPING
|
|
| 1. |
2140-1363A
|
[1] |
PIPE;SUCTION
|
|
| 10. |
2184-1197D79
|
[1] |
HOSE
|
|
| 20. |
2181-2627D1
|
[1] |
ADAPTER
|
|
| 21. |
S8000231
|
[1] |
O-RING
|
|
| 22. |
S8030121
|
[2] |
O-RING
|
|
| 23. |
S8000241
|
[2] |
O-RING
|
|
| 30. |
2180-1026D31
|
[1] |
O-RING
|
|
| 31. |
S2215361
|
[4] |
BOLT;SOCKET M12X1.75X35
|
|
| 41. |
S8450082
|
[4] |
CLAMP;HOSE
|
|
| 50. |
2181-2693A
|
[1] |
ADAPTER
|
|
| 51. |
S8450035
|
[4] |
CLAMP;HOSE
|
|
| 52. |
2181-4133D5
|
[1] |
. ADAPTER
|
|
| 8. |
2185-1002D93
|
[1] |
HOSE
|
|
| 9. |
2185-1002D143
|
[1] |
HOSE 850L
|
|
