神钢零件查询(BREAKER) - ATTACHMENT (N&B) - SK115SR & SK135SR - ASN YV04, YY04, YH04-03001 (9/04-) (02-009) - HYD LINES, BOOM 4.26M (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
766 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV42H00033F1 | [1] | HYD LINES, BOOM 4. 26M | |
| 1. | YV42H01096P1 | [1] | TUBE | KOB |
| 2. | YV42H01082P1 | [1] | TUBE | KOB |
| 3. | YV42H01097P1 | [1] | TUBE | KOB |
| 4. | YV42H01084P1 | [1] | TUBE | KOB |
| 5. | ZE72X16000 | [2] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 6. | ZC26X22011 | [3] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 7. | ZC26X35016 | [3] | CLAMP | KOBSingle Line -- 85x44x38mm (Ø35mm) |
| 8. | YY42H01184P1 | [1] | CLAMP | KOB |
| 9. | ZS18C10045 | [3] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 10. | ZS18C12065 | [1] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 11. | ZS18C14060 | [1] | SCREW,Hex, M14 x 60mm | KOBM14x2.0x60mm |
| 12. | ZW26X10000 | [3] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 13. | ZW26X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 14. | ZW26X14000 | [3] | WASHER | KOBID 14 x OD 24.5 x Th 3.5mm |
| 15. | ZD12A01600 | [1] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 16. | ZD12A01800 | [3] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 17. | ZD12A02100 | [1] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| 18. | YY42H01313P1 | [1] | O-RING,29.87mm ID x 33.43mm OD x 1.78mm | KOBID 29.87 ± 0.15 x OD 33.43mm |
| 19. | ZS18C14065 | [2] | SCREW,Hex, M14 x 65mm | KOBM14x2.0x65mm |
