神钢零件查询(BREAKER) - ATTACHMENT (N&B) - SK115SR & SK135SR - ASN YV04, YY04, YH04-03001 (9/04-) (02-031) - ARM, LONG 2.95M (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
665 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY12B00179F1 | [1] | ARM | KOB |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONARM,LONG |
| 1-7. | 2416T13112 | [1] | BLOCK | KOB Superseded by part number: YY12B01319P1 |
| 1-8. | YY12B01285P1 | [1] | BLOCK | KOB Superseded by part number: YY12B01320P1 |
| 1-9. | YN43H01051P1 | [2] | BLOCK | KOB |
| 2. | LP12B01030P1 | [2] | BUSHING | KOB |
| 3. | YW12B01042P1 | [2] | BUSHING | KOB |
| 4. | YX12B01021P1 | [2] | BUSHING | KOB |
