神钢零件查询(BREAKER) - ATTACHMENT (N&B) - SK115SR & SK135SR - ASN YV04, YY04, YH04-03001 (9/04-) (02-032 ) - ARM, LONG 2.95M (EXTRA, NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
980 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY12B00179F2 | [1] | ARM ASSY,LONG 2.95M | |
| 2. | LP12B01030P1 | [2] | BUSHING | KOB |
| 3. | YW12B01042P1 | [2] | BUSHING | KOB |
| 4. | YX12B01021P1 | [2] | BUSHING | KOB |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 5-7. | 2416T5009D2 | [1] | BLOCK | KOB |
| 5-8. | YY12B01320P1 | [1] | BLOCK | KOB |
| 5-9. | YN43H01051P1 | [2] | BLOCK | KOB |
| 5-10. | 2416T9878D2 | [1] | BLOCK | KOB |
