| 1. |
120100
|
[2] |
BOLT,M6 x 20mm, Cl 8.8
|
NH
|
| 1. |
9706703
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
, Start Serial: D147
|
| 2. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 3. |
9706755
|
[2] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 4. |
364164
|
[4] |
THIN NUT,Thin, M16 x 1.5, Cl 04
|
ZED
Superseded by part number: 10791411
|
| 5. |
84014245
|
[4] |
YOKE
|
ZED
|
| 6. |
330327
|
[4] |
NUT,M12 x 1.5, Cl 8
|
NH
|
| 6. |
331192
|
[4] |
NUT,M16 x 1.5, Cl 8
|
ZED
, Serial Range: -C146 Superseded by part number: 10790521
|
| 7. |
9512527
|
[4] |
FERRULE
|
PA
,, Serial Range: -C015
|
| 8. |
9512532
|
[4] |
O-RING
|
PA
|
| 9. |
9512533
|
[4] |
WASHER, THRUST,16.1mm ID x 22mm OD x 2.6mm Thk
|
PA
|
| 10. |
84007190
|
[4] |
ELBOW,M16 x 1.5 Male
|
ZED
,, Serial Range: -C015
|
| 12. |
84014198
|
[1] |
HOSE,18mm OD x 3.5mm Thk
|
ZED
L = 4.72 M Superseded by part number: 87389513
|
| 13. |
9507812
|
[1] |
CONDUIT
|
CUR
L = 0.85 M Superseded by part number: 9507812BR
|
| 14. |
9512535
|
[1] |
HOSE
|
PA
L = 0.85 M Superseded by part number: 87359227
|
| 15. |
84100076
|
[2] |
3 WAY CONNECTION
|
ZED
|
| 16. |
84100226
|
[2] |
BRACKET
|
ZED
|
| 17. |
84014954
|
[1] |
3 WAY CONNECTION
|
ZED
,, Serial Range: -C015
|
| 17. |
84100075
|
[1] |
3 WAY CONNECTION
|
ZED
,, Start Serial: D016
|
| 18. |
84078896
|
[2] |
CYLINDER
|
ZED
|
| 18. |
84320807
|
[2] |
CYLINDER
|
ZED
|
| 19. |
84014962
|
[2] |
CYLINDER
|
ZED
,, Serial Range: -C015
|
| 19. |
84014961
|
[2] |
CYLINDER
|
ZED
,, Start Serial: D016
|
| 20. |
84014312
|
[4] |
RING
|
ZED
|
| 21. |
84014311
|
[4] |
PLUG
|
ZED
|
| 22. |
84100254
|
[4] |
HYD CONNECTOR
|
ZED
|
| 23. |
150064
|
[4] |
CLAMP
|
ZED
|
| 24. |
86566990
|
[6] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 25. |
84100225
|
[1] |
TUBE,55 mm Length
|
ZED
|
| 26. |
9512534
|
[4] |
HYD CONNECTOR
|
PA
|
| 27. |
10791411
|
[4] |
THIN NUT,Thin, M16, 1.50mm Pitch, 8.00mm High, Cl 04, ZND
|
IMO
|
| 28. |
84078637
|
[2] |
WRAPPER
|
ZED
, Start Serial: D088
|
