神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (01-011) - HYD LINES, UPP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
710 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC03H00011F1 | [1] | HYD LINES, UPP (BREAKER) | |
| . . | LC03H00011F2 | [1] | HYD LINES, UPP (EXTRA & BREAKER) | |
| 1. | 2444Z3722D12 | [1] | HOSE | KOB(F1 ONLY) |
| 2. | ZX40H12086 | [1] | AIR CONDITIONER | KOB Superseded by part number: ZX40H12090 |
| 3. | HH25R16016G2 | [1] | HYD CONNECTOR | KOB1" PF x 81mm Long (Incls. O-Ring ZD12P02900) |
| 4. | ZG23F16016 | [2] | HYD CONNECTOR | KOB1.0"-1.0" PT (Incls. O-Ring 237-6016) |
| 5. | ZG23F12016 | [1] | HYD CONNECTOR | KOB1 3/16" 12UN-1" PT x 48mm Long (Incls. O-Ring 237-6016) |
| 6. | 2444Z3203 | [1] | ELBOW | KOB Superseded by part number: HH35X16016G1 |
| 7. | ZG33F12012 | [1] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB90° -- 1-3/16" -12UN x 3/4" PF (Incls. O-Ring ZD12P02400) |
| 8. | 2444T3395 | [1] | ELBOW | KOB |
| 9. | YN03H01489P1 | [2] | BLOCK | KOB |
| 10. | ZD12A01800 | [2] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 11. | ZD12A02100 | [2] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| 12. | LC03H01075P1 | [1] | BRACKET | KOB |
| 13. | YN03H01432P1 | [1] | BUSHING,28mm ID x 56mm OD x 70mm L | KOBSplit -- ID 28 x OD 38 x 70mm Long |
| 14. | ZW16H12000 | [5] | WASHER | KOBID 13 x OD 26 x Th 3.2mm, (F1 Only) |
| . . | ZW16H12000 | [2] | WASHER | KOBID 13 x OD 26 x Th 3.2mm, (F2 Only) |
| 15. | ZW16H08000 | [8] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 16. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 17. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 18. | ZS18C12035 | [2] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm, (F1 Only) |
| 19. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm, (F1 ONLY) |
| 20. | YN32H01066P1 | [1] | CLAMP | KOB94x38x31mm, (F1 ONLY) |
| 21. | LC03H01082P1 | [1] | SUPPORT | KOB(F1 ONLY) |
| 22. | 2444Z3722D14 | [1] | HOSE | KOB(F2 ONLY) |
| 23. | PY01P01043D6 | [1] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long, (F2 Only) |
