斗山零件查询OIL COOLER PIPING(3) SOLAR 330LC-V Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
892 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
2400-1921A
|
[-] |
OIL COOLER PIPING
|
|
| 12. |
2184-1036D284
|
[1] |
HOSE PF1-900L
|
|
| 13. |
2184-1036D127
|
[1] |
HOSE PF1/2-900L
|
|
| 13. |
2184-1196D69
|
[1] |
HOSE
|
2184-1196D137
|
| 13. |
2184-1196D137
|
[1] |
HOSE UNF1 3/16-720L
|
|
| 14. |
2184-1197D80
|
[1] |
HOSE PF3/16-2100L
|
|
| 14. |
2184-1197D62
|
[1] |
HOSE UNF1 3/16-1300L
|
2184-1197D37
|
| 14. |
2184-1197D39
|
[1] |
HOSE UNF1 3/16-1250L
|
|
| 27. |
S8000231
|
[2] |
O-RING
|
|
| 28. |
S8030121
|
[2] |
O-RING
|
|
| 28. |
S8030121
|
[4] |
O-RING
|
|
| 30. |
S8000381
|
[1] |
O-RING
|
|
| 31. |
S8000291
|
[1] |
O-RING
|
|
| 32. |
2181-1702D48
|
[1] |
ELBOW
|
|
| 33. |
2181-1126D110
|
[1] |
ADAPTER;LONG
|
|
| 34. |
S8000181
|
[2] |
O-RING
|
|
| 34. |
S8000181
|
[1] |
O-RING
|
|
| 35. |
2181-1126D6
|
[2] |
ADAPTER
|
|
| 36. |
2181-2627D1
|
[1] |
ADAPTER
|
|
| 36. |
2181-2627D1
|
[2] |
ADAPTER
|
|
| 50. |
2181-2628D1
|
[1] |
ELBOW
|
|
| 51. |
2181-2766D1
|
[1] |
TEE PF1/2-2XUNF1 3/16
|
|
