| . . | YF30H00001F2 | [1] | HYDR LINES, PUMP | |
| 2. | YN30H01032P1 | [1] | FLEXIBLE HOSE | KOB |
| 3. | YN30H01021D3 | [1] | FLEXIBLE HOSE | KOB |
| 4. | YN30H01021D4 | [1] | HOSE | KOB |
| 5. | ZE13X12000 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 6. | LC52S00012P1 | [2] | SENSOR | KOBPressure (High Pressure) (replaced by LS52S00015P1) Superseded by part number: YY52S00033F1 |
| 6. | LS52S00015P1 | [2] | SENSOR | KOB(New part #) (Added by SB S030-41-K003) |
| 6-0. | YY52S00033F1 | [1] | PRESSURE SWITCH | KOBKit Includes Ref 6 - 6-3 (Refer to SB S030-41-K003) |
| 6-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 6-2. | LS30H01024P1 | [1] | HYD CONNECTOR | SM(Added with new part # press switch) |
| 6-3. | YT42H01128P1 | [1] | 90 ELBOW | KOB(Added with new part # press switch) |
| 7. | PY01P01043D3 | [2] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 8. | ZC16X09100 | [4] | CLIP | KOBClamp, Hose -- Min 80 x Max 101mm |
| 9. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 10. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 11. | ZS28C12045 | [4] | SCREW,Hex Socket Head, M12 x 45mm | KOBM12x1.75x45mm |
| 12. | ZS18C10035 | [8] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 13. | ZW26K12000 | [4] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 14. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 15. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 15-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 16. | YN64H01018P1 | [1] | GROMMET | KOB |
| 17. | YN30H01035P1 | [1] | GROMMET | KOB |
| 18. | YN30H01036P1 | [1] | TUBE | KOB |
| 19. | YN06H01022P1 | [1] | HOSE | KOB |
| 20. | ZC16X03300 | [2] | FASTENER | KOBClamp, Hose -- Min 26 x Max 39mm |
| 21. | YN30H01048P1 | [1] | TUBE | KOB |
| 22. | ZS28C10035 | [4] | SCREW,Hex Socket Head, M10 x 35mm | KOBScrew -- M10x1.50x35mm |
| 23. | ZW26K10000 | [4] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 24. | ZD11P04100 | [1] | O-RING | KOB |
| 25. | YF30H01001P1 | [2] | WASHER | KOB |
| 26. | ZS28C10025 | [2] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm |
| 27. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 27-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
