神钢零件查询(EXTRA) - AND BREAKER ATTACHMENT - K907 II ASN YN0101 & K907LC II ASN YQ0101 (1/88-12/06) (04-005) - INSTAL HYD LINES, ARM, 2.94M (EXTRA & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1014 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N5440F1 | [1] | INSTALL HYDR LINES | |
| 1. | 2418T16673 | [1] | TUBE | |
| 2. | 2418T16672 | [1] | TUBE | |
| 3. | 2418P18854D2 | [1] | TUBE | |
| 4. | 2418P18854D1 | [1] | TUBE | |
| 5. | 2418P18852 | [1] | TUBE | |
| 6. | 2418P18853 | [1] | TUBE | |
| 7. | 2418P12141D3 | [1] | TUBE | |
| 8. | 2418P12141D4 | [1] | TUBE | |
| 9. | 2444Z2518D2 | [1] | HOSE | KOB |
| 10. | ZX56N12160 | [1] | HOSE | |
| 11. | 2418T12187D1 | [1] | PLATE | |
| 12. | 2418T12187D2 | [1] | PLATE | |
| 14. | 2416T13074D2 | [2] | BLOCK, TAPPED | |
| 15. | 2416T12924D3 | [3] | LINK BLOCK | KOB |
| 16. | 2416T12924D2 | [1] | BLOCK | KOB |
| 18. | 2416T9878D5 | [2] | CONNECTING BLOCK | KOB |
| 19. | ZC26X35016 | [5] | CLAMP | KOBSingle Line -- 85x44x38mm (Ø35mm) |
| 20. | ZC26X28014 | [1] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 21. | ZC36X18011 | [3] | CLAMP | KOB |
| 22. | 2444T2406 | [2] | PLUG | KOBCap -- 1-5/16" 12UNF |
| 23. | 2420T4384 | [4] | PLUG | KOB |
| 24. | 24100P1005F1 | [2] | VALVE | KOBSELECTOR Superseded by part number: 24100P1005F3 |
| 24-1. | 2436P229 | [1] | VALVE BODY | KOB |
| 24-2. | 2436T303 | [1] | VALVE | KOB |
| 24-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 24-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 24-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 24-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 24-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 24-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 24-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 24-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 25. | 2444T2453D1 | [2] | CONNECTOR | |
| 26. | 2444Z2093 | [3] | HYD CONNECTOR | KOB |
| 27. | ZA23F28012 | [1] | HYD CONNECTOR | KOB |
| 28. | 2444Z2225 | [4] | HYD CONNECTOR | KOB |
| 29. | ZA53B18000 | [2] | TEE | KOB |
| 30. | ZD12P02240 | [6] | O-RING | KOBID 22.10 ± 0.24 x OD 28.4mm |
| 31. | ZS13C14060 | [5] | SCREW | KOBM14x2.0x60mm Superseded by part number: ZS18C14060 |
| 32. | ZS13C12055 | [1] | SCREW | KOBM12x1.75x55mm Superseded by part number: ZS18C12055 |
| 33. | ZS13C10045 | [2] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
| 34. | ZW22X14000 | [5] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 35. | ZW22X12000 | [1] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 36. | ZW22X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
