神钢零件查询(NIBBLER) - & BREAKER - SK70SR-1E SHORT RADIUS EXCAVATOR ASN YT02-04001 (4/03-12/04) (06-069[00]) - FLOOR PLATE GROUP, (YT03M00027F2, YT03M00027F3, YT03M00027F4 & YT03M00027F5) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
173 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YT03M01112P1 | [1] | SUPPORT | KOB(F2 & F3 Only) |
| 3. | YN03M01201P1 | [1] | COVER | KOB(F2 & F3 Only) |
| 5. | YN03M01062P3 | [2] | COVER | KOB |
| 6. | YT03M01077P2 | [1] | SUPPORT | KOB |
| 7. | ZM22C08020 | [7] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 8. | ZM22C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher), (F2 & F3 Only) |
| 10. | YT26M00023P1 | [1] | MAT | KOBFloor, (F2 Only) |
| 11. | YT26M00024P1 | [1] | MAT | KOBFloor, (F3 Only) |
| 12. | YT26M00025P1 | [1] | MAT | KOBFloor, (F4 Only) |
| 13. | YT26M00026P1 | [1] | MAT | KOBFloor, (F5 Only) |
