斗山零件查询LEVER - BOOM SWING / 1 & 2 WAY E80 Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
521 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
K1036853A
|
[-] |
LEVER;B/S & 1or 2WAY
|
|
| -. |
101101-00071
|
[-] |
|
|
| -. |
101101-00071A
|
[-] |
|
|
| 1. |
K1043128A
|
[2] |
PEDAL ASS'Y
|
110435-00026
|
| 1. |
110435-00026
|
[2] |
|
|
| 2. |
K1042989
|
[2] |
RUBBER;PEDAL
|
180308-00053
|
| 2. |
180308-00053
|
[2] |
|
|
| 3. |
K1033022A
|
[2] |
LATCH
|
|
| 31. |
K1036846B
|
[1] |
BRACKET
|
|
| 32. |
K1006656
|
[1] |
RUBBER,PEDAL
|
|
| 33. |
2120-2166D5
|
[4] |
BOLT
|
|
| 34. |
2114-1898D2
|
[4] |
WASHER
|
|
| 4. |
2120-2166D5
|
[8] |
BOLT
|
|
| 5. |
2114-1898D2
|
[8] |
WASHER
|
|
