纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (01-014) - TANK ASSY, FUEL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
855 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YF20P00002F2 | [1] | TANK ASSY, FUEL | |
| A2. | YN20P01034P2 | [1] | CAP | KOBFILLER |
| A3. | YY50V00001P1 | [1] | STRAINER ASSY. | KOB |
| A5. | ZD11P13000 | [1] | O-RING | KOB |
| A6. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOB |
| A7. | ZW16X10000 | [4] | WASHER | KOB |
| A8. | ZE82T04000 | [1] | PLUG | KOB |
| . . | YF20P00003F1 | [1] | TANK INSTAL, FUEL | |
| B1. | ZS18C16045 | [4] | SCREW,Hex, M16 x 45mm | KOBCAP |
| B2. | ZW16H16000 | [4] | WASHER | KOB |
| B3. | LE33H01017D1 | [3] | SHIM | KOB(1.0) |
| B4. | YF52S00001F1 | [1] | SENSOR | KOBSENDING UNIT, FUEL |
| B5. | 2418T9962 | [1] | PACKING | KOB |
| B6. | ZS31C05012 | [5] | BOLT,Phillips Drive, Pan HD, M5 x 12mm | KOBMACHINE SCREW |
| B7. | ZW26X05000 | [5] | LOCK WASHER | KOBLOCK |
| B9. | LC25V00001P1 | [1] | COCK | KOBVALVE, STOP, Serial Range: YU04-00837-YU04-01005 Superseded by part number: LC25V00001P2 |
| B9. | LC25V00001P2 | [1] | COCK | KOBVALVE, STOP, Start Serial: YU04-01006 |
| B18. | ZC16X01400 | [1] | CLIP | KOB |
| B20. | YN20P01040P1 | [1] | STAY | KOBSTAY |
| B21. | ZM32C12030 | [3] | BOLT | KOBSEMS |
| B22. | ZM32C12025 | [4] | BOLT | KOBSEMS |
