纽荷兰零件查询(E235SRLC) - CRAWLER EXCAVATOR BTW YU04-00837 - YU04-01417 (05-009) - HYD LINES, CYLINDER (ARM SAFETY) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
665 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YN01V00132F4 | [1] | HYDRAULIC CYLINDER | KOBASSY, ARM |
| . . | YN42H00226F2 | [1] | HYD LINES, CYLINDER | |
| 1. | YN28V00008F4 | [1] | VALVE | KOBASSY, HOLDING Superseded by part number: YN28V00008F7 |
| 3. | YN42H01934D1 | [1] | HOSE | KOB |
| 4. | YN02B01030D1 | [1] | HYDRAULIC HOSE | KOB |
| 7. | ZE13X16000 | [2] | FLANGE | KOBCLAMP, HALF |
| 8. | YN43H01097P1 | [1] | CLAMP | KOB |
| 9. | HG33H16016G1 | [1] | ELBOW | KOB |
| 10. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 11. | HH25X06006GA | [1] | HYD CONNECTOR | KOB |
| 12. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB |
| 13. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOBGREASE |
| 14. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| 15. | ZD12A02100 | [1] | O-RING | KOB |
| 16. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOB |
| 17. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBCAP |
| 18. | ZS28C12065 | [4] | SCREW,Hex Socket Head, M12 x 65mm | KOBCAP |
| 19. | ZS28C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBCAP |
| 20. | ZW26X12000 | [1] | WASHER | KOB |
| 21. | ZW26K12000 | [8] | LOCK WASHER | KOB |
| 22. | ZE72X08000 | [1] | PLUG | KOB |
| 23. | PY01P01043D3 | [21] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 30. | 2420R537D430 | [1] | HOSE,9.60mm ID x 4300mm L | KOBHOSE |
