凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (05.29[01]) - LARGE STEERED TANDEM AXLE, REAR, END - NOT FOR NA - D800 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
860 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84212709
|
[2] |
PIN
|
ZED
|
| 2. |
84220999
|
[2] |
LOCK WASHER
|
ZED
|
| 3. |
100024
|
[2] |
NUT,M24 x 1.5, Cl 8
|
MKT
|
| 4. |
87612526
|
[4] |
BRAKE SHOE
|
ZED
|
| 5. |
84212731
|
[4] |
BRAKE SPRING
|
ZED
|
| 6. |
84807629
|
[2] |
SEALING RING
|
ZED
|
| 7. |
84041878
|
[2] |
TAPERED BEARING
|
ZED
Superseded by part number: 9832270
|
| 8. |
84100478
|
[2] |
RING
|
ZED
|
| 9. |
84041877
|
[2] |
SEALING RING
|
ZED
SEALRING
|
| 10. |
84041879
|
[2] |
TAPERED BEARING
|
ZED
|
| 11. |
87693636
|
[2] |
HUB
|
ZED
|
| 12. |
84043371
|
[2] |
DRUM
|
ZED
|
| 13. |
84014229
|
[16] |
BOLT
|
ZED
Superseded by part number: 87472615
|
| 14. |
84100479
|
[2] |
NUT
|
ZED
|
| 15. |
84212727
|
[2] |
COTTER PIN
|
ZED
|
| 16. |
84100510
|
[2] |
COVER
|
ZED
|
| 17. |
14301931
|
[12] |
HEX SOC SCREW,M8 x 1.25 x 10mm, Cl 10.9, Full Thd
|
LEC
|
| 18. |
84045545
|
[16] |
WHEEL NUT
|
ZED
, Serial Range: -C859 Superseded by part number: 84288019
|
| 18. |
84288019
|
[16] |
WHEEL NUT
|
PLO
, Start Serial: D860
|
| 19. |
84288018
|
[1] |
KIT
|
PLO
(18), (SET OF 16)
|
