纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-009-00[01]) - WATER CIRCUIT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1010 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUH0113 | [1] | RADIATOR | SUM |
| 33. | 102R020Y045R | [4] | BOLT | SUMM20 x 45 |
| 34. | 150817A1 | [4] | WASHER,21mm ID x 40mm OD x 4.5mm Thk | SUM |
| 35. | KUH0134 | [1] | STAY | SUM |
| 36. | KUH0111 | [1] | STAY | SUM |
| 37. | 102R020Y035R | [4] | BOLT | SUMM20 x 35 |
| 39. | KUH0132 | [1] | RADIATOR HOSE | SUM |
| 40. | KUH0133 | [1] | RADIATOR HOSE | SUM |
| 41. | 165795A1 | [4] | COLLAR | SUM |
| 42. | KUH0124 | [1] | TANK | SUM |
| 43. | KUH0144 | [1] | BRACKET | SUM |
| 44. | 627-12035 | [2] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 45. | 150811A1 | [2] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 46. | KUH0043 | [1] | HOLDER | SUM |
| 47. | 166351A1 | [2] | BOLT,Sems, M10 x 20mm | SUM |
| 48. | 165951A1 | [1] | CLAMP | SUM |
| 49. | KHH0427 | [1] | HOSE | SUM Superseded by part number: KHH12900 |
| 50. | 165952A1 | [1] | MOUNTING CLIP | SUM |
| 51. | KUH0127 | [1] | BRACKET | SUM |
| 54. | KUH0128 | [1] | RADIATOR HOSE | SUM Superseded by part number: KUH10560 |
| 55. | 150294A1 | [2] | CLAMP,95mm - 115mm | SUM |
| 56. | KUH0130 | [1] | BRACKET | SUM |
| 59. | KUH0131 | [1] | AIR FLEXIBLE | SUM |
| 61. | 152782A1 | [1] | COLLAR | SUM |
| 62. | 150071A1 | [1] | MOUNTING CLIP | SUM |
