纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-011-00[01]) - WATER CIRCUIT - RADIATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
928 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUH0113 | [1] | RADIATOR | SUM |
| 2. | KTH0635 | [2] | RADIATOR HOSE | SUM |
| 3. | 150294A1 | [4] | CLAMP,95mm - 115mm | SUM |
| 4. | KUH0125 | [1] | PIPE ASSY. | SUM |
| 5. | KUH0129 | [1] | PIPE ASSY. | SUM |
| 6. | KUH0126 | [2] | BRACKET | SUM |
| 7. | 152718A1 | [6] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 8. | 150487A1 | [1] | HOSE | SUM |
| 9. | 150401A1 | [1] | PLASTIC-RUBBER TUBE,13 mm ID, 17.5 mm OD, 1000 mm Length | SUM Superseded by part number: |
| 10. | 165951A1 | [1] | CLAMP | SUM |
| 11. | KUH0135 | [1] | SEAL | SUM |
| 12. | KUH0141 | [1] | BRACKET | SUM |
| 13. | 166345A1 | [3] | BOLT | SUM Superseded by part number: 105R008Y016R |
| 14. | KUH0136 | [1] | SEAL | SUM |
| 15. | KUH0139 | [1] | SEAL | SUM |
| 16. | KHH0358 | [7] | RETAINER | SUM |
| 17. | 627-8040 | [7] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9, Full Thd | SUM |
| 18. | 895-11008 | [7] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
| 19. | KUH0142 | [1] | BRACKET | SUM |
| 21. | KUH0137 | [1] | SEAL | SUM |
| 24. | 827-8040 | [6] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9 | CAS Superseded by part number: 9780069 |
| 26. | KUH0143 | [1] | BRACKET | SUM |
| 28. | KUH0138 | [1] | SEAL | SUM |
| 29. | KUH0140 | [1] | PAD, RUBBER | SUM |
