纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-011-01[01]) - RADIATOR ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
580 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | KUH0113 | [1] | RADIATOR | SUM |
| . . | LN00073 | [1] | RADIATOR | SUM |
| 2. | LN00074 | [1] | RADIATOR | SUM |
| 3. | LW00358 | [1] | TANK | SUM |
| 4. | LW00359 | [1] | TANK | SUM |
| 5. | LS00171 | [1] | SUPPORT | SUM |
| 6. | LS00172 | [1] | SUPPORT | SUM |
| 7. | LR00755 | [4] | SUPPORT | SUM |
| 8. | LA00792 | [24] | BOLT | SUM |
| 9. | LA00793 | [44] | BOLT | SUM |
| 10. | LE00914 | [2] | GASKET | SUM |
| 11. | LR00756 | [4] | PLATE | SUM |
| 12. | LR00757 | [4] | PLATE | SUM |
| 13. | LR00758 | [2] | PLATE | SUM |
| 14. | LA00794 | [92] | BOLT | SUM |
| 15. | LR00759 | [2] | PLATE | SUM |
| 16. | LE00915 | [2] | SET OF PARTS | SUM |
| 17. | LR00650 | [1] | FILLER CAP | SUM |
| 18. | LJ00849 | [1] | COCK, DRAIN | SUM |
| 19. | LK00342 | [1] | HOSE | SUM |
| 20. | LA00602 | [1] | CLIP,ELECTRICAL | SUM |
| 21. | LW00360 | [1] | SHROUD | SUM |
| 22. | LA00781 | [12] | BOLT | SUM Superseded by part number: LA00792 |
| 23. | LM00069 | [1] | GUARD | SUM |
| 25. | LN00075 | [1] | COOLER, OIL | SUM |
| 26. | 158869A1 | [8] | BOLT | SUM |
| 27. | LG00393 | [1] | PROTECTOR | SUM |
| 28. | LG00394 | [1] | PROTECTOR | SUM |
| 29. | 156606A1 | [4] | BOLT,Wing, M6 | SUM |
| 30. | LS00173 | [2] | BRACKET | SUM |
| 32. | LL00082 | [1] | CONDENSER | SUM |
| 33. | LUG0033 | [4] | BOLT,Spcl | SUM |
| 34. | LG00395 | [1] | SIEVE | SUM |
| 36. | LR00760 | [2] | LARGE PLATE | SUMPLATE, LARGE |
| 38. | LE00916 | [2] | PACKING | SUM |
| 39. | LE00917 | [2] | PACKING | SUM |
