纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-043-00[01]) - CYLINDER HEAD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
650 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 288542A1 | [1] | HEAD (CYLINDER) | ISUCYLINDER HEAD Superseded by part number: 87738593 |
| 4. | 288548A1 | [24] | GUIDE | ISU |
| 5. | 288549A1 | [12] | SEAT, VALVE | ISU |
| 6. | 288550A1 | [12] | VALVE SEAT | ISU Superseded by part number: 72110160 |
| 7. | 362152A1 | [2] | CUP | CAS |
| 8. | 289076A1 | [10] | CUP | ISUdia 25 |
| 9. | 289414A1 | [2] | CUP | ISUdia 12,3 Superseded by part number: 368335A1 |
| 10. | 353962A1 | [6] | PLUG | ISUdia 16 |
| 11. | 359866A1 | [12] | CUP | CAS18 OD |
| 12. | 288553A1 | [18] | PLUG | ISU40 OD |
| 57. | 288561A1 | [6] | ENGINE VENT SLEEVE | ISU |
| 58. | 288562A1 | [6] | GASKET | ISU Superseded by part number: 72110172 |
| 59. | 288563A1 | [6] | GASKET | ISU Superseded by part number: 72110173 |
