纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (02-049-00[01]) - CYLINDER HEAD COVERS AND GASKET New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
647 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 86993403 | [1] | VALVE COVER | ISU |
| 2. | 426076A1 | [1] | BREATHER | ISU |
| 4. | 288798A1 | [1] | FILLER CAP | ISU |
| 5. | 288797A1 | [1] | GASKET | ISU Superseded by part number: 72109500 |
| 28. | 288997A1 | [20] | BOLT | ISUM8 x 35; 10,9 Superseded by part number: 87595258 |
| 29. | 288539A1 | [1] | GROMMET | ISU Superseded by part number: 87432192 |
| 69. | 87420797 | [1] | GASKET | ISU |
| 72. | 288541A2 | [1] | PLATE | ISU |
| 76. | 288693A1 | [1] | BOLT | ISUM6 x 100 |
