纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (03-013-00[01]) - INJECTOR - FUEL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
748 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 16. | 426399A1 | [1] | PIPE | ISU Superseded by part number: 72110387 |
| 17. | 426400A1 | [1] | PIPE | ISU Superseded by part number: 72110388 |
| 18. | 426401A1 | [1] | PIPE | ISU Superseded by part number: 72110389 |
| 19. | 426402A1 | [1] | PIPE | ISU Superseded by part number: 72110390 |
| 20. | 426403A1 | [1] | PIPE | ISU Superseded by part number: 72110391 |
| 21. | 426404A1 | [1] | PIPE | ISU Superseded by part number: 72110392 |
| 31. | 426405A1 | [6] | INJECTOR ASSY. | ISU |
| 38. | 443714A1 | [6] | GASKET | ISU |
| 57. | 443717A1 | [6] | GASKET | ISU |
| 58. | 426408A1 | [6] | COUPLING FLANGE | ISU Superseded by part number: 72110404 |
| 61. | 426409A1 | [6] | BOLT | ISU |
| 66. | 426410A1 | [6] | GASKET | ISUOD 15 |
| 69. | 426411A1 | [1] | SUPPORT | ISU |
| 70. | 426412A1 | [1] | SUPPORT | ISU |
| 71. | 419935A1 | [4] | BOLT | ISUM8 x 16 Superseded by part number: 76599954 |
| 107. | 426414A1 | [6] | FLANGE NUT | ISUM6 Superseded by part number: 72959554 |
| 113. | 426415A1 | [14] | CLIP | ISU |
| 118. | 426416A1 | [1] | BOLT | ISUM6 x 40 |
| 124. | 426418A1 | [9] | BOLT | ISUM8 x 18 |
| 126. | 438172A1 | [9] | GASKET | ISUID 8,6 |
| 137. | 426421A1 | [1] | PIPE | ISU |
| 163. | 426422A1 | [6] | FLANGE COVER CAP | ISU |
