| . . | YY12B00149F1 | [1] | ARM | KOBGROUP |
| A1. | YY12B01249F1 | [1] | LINK | KOBASSY, BUCKET |
| A1-1. | NSS | [1] | NOT SOLD SEPARAT | CONLINK, BUCKET |
| A1-2. | LP12B01031P1 | [2] | BUSHING | KOB |
| A1-3. | LP12B01036P1 | [2] | BUSHING | KOB |
| A2. | YY12B01074P1 | [1] | LINK | KOB |
| A3. | YW12B01034P1 | [1] | LINK | KOB |
| A4. | YY12B01242P1 | [2] | PIN | KOB |
| A5. | LP12B01028P1 | [1] | PIN | KOB Superseded by part number: YX12B01042P1 |
| A6. | LP12B01029P1 | [1] | PIN | KOB Superseded by part number: YX12B01042P1 |
| A7. | HS18C14115G2 | [2] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOBM14x2.0x150mm |
| A8. | ZN18C14011 | [4] | NUT | KOBM14x2.0mm |
| A9. | 2445R220D2 | [4] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| A10. | 2445R138D3 | [6] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBDust -- ID 60 x OD 75 x Th 4mm |
| A11. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| A12. | ZG91S02000 | [4] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A13. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| A14. | YW12B01025P1 | [6] | SHIM,62mm ID x 100mm OD x 3mm Thk | KOBID 62 x OD 100 x Th 3.0mm |
| A15. | B16T0442D56 | [6] | SHIM,62mm ID x 100mm OD x 0.5mm Thk | KOBID 62 x OD 100 x Th 0.5mm |
| A16. | B16T0442D43 | [6] | SHIM,62mm ID x 100mm OD x 0.9mm Thk | KOBID 62 x OD 100 x Th 0.9mm |
| A17. | B16T0442D27 | [6] | SHIM,62mm ID x 100mm OD x 1.2mm Thk | KOBID 62 x OD 100 x Th 1.2mm |
| A18. | B16T0442D19 | [6] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOBID 62 x OD 100 x Th 1.6mm |
| . . | YY12B00061FE | [1] | ARM | KOBASSY, Serial Range: YH02-01301-YH02-01335 |
| . . | YY12B00176F1 | [1] | ARM | KOBASSY, Start Serial: YH02-01336- |
| B1. | NSS | [1] | NOT SOLD SEPARAT | CON, Start Serial: YH02-01336- |
| B1-2. | YY12B01044P1 | [1] | PLATE | KOB |
| B1-3. | 2416T13112 | [1] | BLOCK | KOBTAPPED Superseded by part number: YY12B01319P1 |
| B1-4. | YY12B01285P1 | [1] | BLOCK | KOBTAPPED Superseded by part number: YY12B01320P1 |
| B1-5. | YN43H01051P1 | [2] | BLOCK | KOBTAPPED |
| B2. | LP12B01030P1 | [2] | BUSHING | KOB |
| B3. | YW12B01042P1 | [2] | BUSHING | KOB |
| B4. | YX12B01021P1 | [2] | BUSHING | KOB |
| B14. | NSS | [1] | NOT SOLD SEPARAT | CON, Serial Range: YH02-01301-YH02-01335 |
| B14-2. | YY12B01044P1 | [1] | PLATE | KOB |
| B14-3. | 2416T13112 | [2] | BLOCK | KOBTAPPED Superseded by part number: YY12B01319P1 |
| B14-4. | YN43H01051P1 | [2] | BLOCK | KOBTAPPED |
| . . | YY12B00003F1 | [1] | ARM | KOBASSY |
| C1. | LP02B01012P2 | [1] | PIN | KOB |
| C2. | YY02B01062P1 | [1] | PIN | KOB |
| C3. | 2418T12645D2 | [1] | PLATE | KOB125 x 261 x Th 9.0mm |
| C4. | ZS18C12020 | [2] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| C5. | HS18C16140G2 | [1] | SCREW,M16 x 140mm, Cl 10.9 | KOBM16x2.0x140mm |
| C6. | ZN18C16013 | [2] | NUT | KOBM16x2.0mm |
| C7. | B16T0442D44 | [3] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| C8. | YN12B01009P1 | [4] | SHIM,3mm Thk | KOB(3.0) |
| C9. | B16T0442D57 | [3] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| C10. | B16T0442D1 | [1] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| C11. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
