神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (09-051) - REDUCTION ASSY (SWING) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
241 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX32W00002F1 | [1] | MOTO-REDUCTION GEAR | KOBASSY (SWING) Superseded by part number: YX32W00002F2 |
| . . | YX32W00002F2 | [1] | MOTO-REDUCTION GEAR | KOBASSY (SWING) |
| 102. | YX32W00002S102 | [1] | CASE | KOBBODY |
| 201. | YX32W00002S201 | [1] | SHAFT | KOB |
| 202. | YX32W00002S202 | [1] | GEAR | KOB |
| 203. | YX32W00002S203 | [4] | GEAR | KOB |
| 204. | YX32W00002S204 | [1] | GEAR | KOB |
| 210. | YX32W00002S210 | [3] | GEAR | KOB |
| 211. | YX32W00002S211 | [1] | GEAR | KOB |
| 230. | YX32W00002S230 | [1] | CARRIER | KOBSPIDER |
| 231. | NSS | [1] | NOT SOLD SEPARAT | CONSPIDER |
| 282. | YX32W00002S282 | [4] | PIN | KOB |
| 283. | NSS | [3] | NOT SOLD SEPARAT | CONPIN |
| 285. | YX32W00002S285 | [7] | PLATE | KOB |
| 286. | YX32W00002S286 | [1] | WASHER | KOB |
| 287. | YX32W00002S287 | [3] | PLATE | KOB |
| 311. | YX32W00002S311 | [1] | DIPSTICK | KOBBAR, LEVEL |
| 312. | YX32W00002S312 | [1] | PIPE | KOBTUBE |
| 401. | YX32W00002S401 | [1] | ROLLER BEARING | KOB |
| 402. | YX32W00002S402 | [1] | ROLLER BEARING | KOBFOR F2&F3) |
| 403. | YX32W00002S403 | [3] | NEEDLE BEARING | KOB |
| 602. | ZS23C12100 | [10] | CAPSCREW,Hex Socket Head, M12 x 100mm | KOBSCREW M12x1.75x100mm |
| 801. | YX32W00002S801 | [1] | OIL SEAL | KOB |
| 902. | 2453U439S905 | [2] | PLUG | KOB(FOR F1 ONLY) |
| 910. | 2453U276S287 | [4] | PIN | KOBSPRING |
| 911. | 2441U398S820 | [3] | RING | KOBRETAINING Superseded by part number: ZR16X03000 |
| 912. | ZR16X02500 | [1] | RING | KOBRetaining -- ID 23.2 x OD 25 x Th 1.2mm |
| 913. | 2441U333S825 | [1] | SNAP RING | KOBRETAINING Superseded by part number: ZR16X06500 |
| 915. | YX32W00002S915 | [1] | SEAL | KOB Superseded by part number: EW32W00003S915 |
| 920. | YX32W00002S920 | [1] | ADAPTER | KOB |
| 921. | YX32W00002S921 | [1] | HOSE | KOB |
| 922. | YX32W00002S922 | [1] | PLUG | KOB |
| 925. | YX32W00002S925 | [1] | BREATHER | KOBNIPPLE,GREASE(FOR F2 ONLY) |
| 926. | YX32W00002S926 | [1] | LUBE NIPPLE | KOBGREASE(FOR F2 ONLY) |
| . . | YX32W00002R100 | [1] | REPAIR KIT | KOBCONSISTS OF ITEM 231X1, 283X3 |
