凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (13.05[01]) - PICK-UP, FRAME Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
301 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
9837884
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 2. |
333228
|
[1] |
KEY,10mm W x 8mm H x 40mm L
|
ZED
|
| 3. |
84607747
|
[1] |
AUGER
|
ZED
|
| 3. |
84607794
|
[1] |
AUGER
|
ZED
|
| 4. |
84607750
|
[1] |
AUGER
|
ZED
|
| 4. |
84607795
|
[1] |
AUGER
|
ZED
|
| 5. |
84801631
|
[27] |
GUARD
|
ZED
, Serial Range: -C799 Superseded by part number: 84468627
|
| 5. |
84214800
|
[27] |
GUARD
|
ZED
, Serial Range: -F800895 Superseded by part number: 84468627
|
| 5. |
84468627
|
[27] |
GUARD
|
ZED
, Start Serial: D896
|
| 6. |
9837885
|
[1] |
DRIVEN SPROCKET
|
ZED
|
| 7. |
9837842
|
[4] |
BEARING,35mm ID x 72mm OD x 19mm W
|
ZED
|
| 8. |
36403
|
[8] |
BEARING HOUSING
|
GI
Superseded by part number: 578189
|
| 9. |
9837838
|
[1] |
KEY
|
ZED
|
| 10. |
87676773
|
[1] |
FRAME
|
ZED
, Serial Range: -C799
|
| 10. |
84208839
|
[1] |
FRAME
|
ZED
, Start Serial: D800
|
| 10. |
87616545
|
[1] |
FRAME
|
ZED
, Serial Range: -C799
|
| 10. |
84199628
|
[1] |
FRAME
|
ZED
, Start Serial: D800
|
| 11. |
84607749
|
[2] |
ANGLE
|
ZED
|
| 11. |
84607748
|
[2] |
SKID PLATE
|
ZED
|
| 12. |
85005505
|
[1] |
GUIDE
|
ZED
|
| 12. |
84074993
|
[1] |
GUIDE
|
ZED
|
| 12. |
85005504
|
[1] |
GUIDE
|
ZED
|
| 13. |
140045
|
[18] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 14. |
86511478
|
[54] |
BOLT,Hex Serr, M8 x 1.25 x 16mm
|
ZED
|
| 15. |
120041
|
[18] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 16. |
100016
|
[18] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 17. |
322358
|
[12] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 18. |
9706690
|
[8] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 19. |
43127
|
[4] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 20. |
308761
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
