| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 2. | 166351A1 | [4] | BOLT,Sems, M10 x 20mm | SUM |
| 3. | 159285A1 | [1] | PLUG | SUM |
| 4. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 5. | KHJ1588 | [1] | SPRING | SUM |
| 6. | KHJ1564 | [1] | COVER | SUM |
| 7. | KHJ1404 | [1] | O-RING | SUM |
| 8. | 159282A1 | [1] | HYDRAULIC OIL FILTER | SUM |
| 9. | KHJ2592 | [1] | HOUSING | SUM |
| 10. | 166347A1 | [4] | BOLT,Sems, M10 x 30mm | SUM |
| 11. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 13. | 159043A1 | [1] | HOSE ASSY. | SUM |
| 14. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 16. | KHJ1265 | [1] | HYDRAULIC HOSE | SUM |
| 20. | 150960A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM Superseded by part number: 154467A1 |
| 27. | 159497A1 | [1] | TEE | SUM |
| 29. | 151877A1 | [1] | HOSE,63.00 mm ID x 1200.00 mm | SUM |
| 30. | 159848A1 | [1] | ORIFICE | SUM |
| 34. | 162563A1 | [1] | HOSE ASSY. | SUM800 mm (31-1/2 in) |
| 35. | 150933A1 | [1] | ELBOW | SUM |
