纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-019-00[01]) - HYDRAULICS DRAIN LINE - WITHOUT LOAD HOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
873 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 156664A1 | [1] | STUD | SUM |
| 2. | 154503A1 | [1] | O-RING | SUM |
| 3. | KUJ0241 | [1] | HYDRAULIC HOSE,19.00 mm ID x 2000.00 mm | SUM |
| 4. | 157867A1 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHR21080 |
| 5. | 151654A1 | [1] | HYD CONNECTOR,3/4" NPT O-Ring x 3/4" NPT | SUM |
| 7. | 168609A1 | [1] | ELBOW | SUM |
| 8. | KUJ0238 | [1] | HYDRAULIC HOSE,19.00 mm ID x 470.00 mm | SUM |
| 9. | 163114A1 | [1] | TEE | SUM |
| 10. | 154487A1 | [1] | O-RING | SUM |
| 11. | KTJ2094 | [1] | HYDRAULIC HOSE,19.05 mm ID x 1100.00 mm | SUM |
| 14. | 157580A1 | [1] | ELBOW,90º, 3/4" O-Ring x 3/4" | SUM |
| 16. | KUJ0110 | [1] | HYDRAULIC HOSE,19.00 mm ID x 2350.00 mm | SUM |
| 17. | 151012A1 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHR21080 |
| 22. | KRJ4590 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1650.00 mm | SUM |
| 23. | 157865A1 | [1] | TUBE,28 mm ID, 34 mm OD, 800 mm Length | SUM Superseded by part number: KHR21080 |
| 26. | KTJ2096 | [1] | BRACKET | SUM |
| 27. | 166351A1 | [2] | BOLT,Sems, M10 x 20mm | SUM |
| 28. | 161163A1 | [2] | COLLAR | SUM |
| 29. | 150071A1 | [1] | MOUNTING CLIP | SUM |
| 30. | 150860A1 | [1] | COLLAR | SUM |
| 31. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
