| 1. | 150919A1 | [1] | ELBOW,90º, 1/2" O-Ring x 1/2" | SUM |
| 2. | 154487A1 | [1] | O-RING | SUM |
| 3. | KAJ2882 | [1] | HYDRAULIC HOSE,12.70 mm ID x 800.00 mm | SUM |
| 4. | 151650A1 | [1] | HYD CONNECTOR,1/2" NPT O-Ring x 1/2" NPT | SUM |
| 6. | KHJ2562 | [1] | MANIFOLD | SUM |
| 7. | 153233A1 | [1] | HYDRAULIC OIL FILTER | SUM Superseded by part number: MMJ80010 |
| 7A. | 164690A1 | [1] | O-RING | SUM |
| 8. | 166350A1 | [3] | BOLT | SUM |
| 9. | KHJ1553 | [1] | ACCUMULATOR | SUM Superseded by part number: KHJ17540 |
| 10. | KUJ0319 | [1] | BRACKET | SUM |
| 11. | 152718A1 | [4] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 12. | KHJ2304 | [1] | SOLENOID VALVE | SUM Superseded by part number: KHJ15470 |
| 13. | 166351A1 | [4] | BOLT,Sems, M10 x 20mm | SUM |
| 14. | 161551A1 | [1] | COVER | SUM |
| 15. | 156559A1 | [2] | BOLT,High Strength, Hex, M6 x 12mm, W/ LW | SUM |
| 18. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 19. | 154467A1 | [4] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 20. | 159002A1 | [1] | PLUG | SUM |
| 22. | 152128A1 | [2] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 23. | 154475A1 | [2] | O-RING | SUM |
| 24. | 162554A1 | [2] | FITTING | SUM |
| 27. | KHJ1247 | [1] | HYDRAULIC HOSE | SUM |
| 28. | KHJ1248 | [1] | HYDRAULIC HOSE | SUM |
| 29. | KHJ1931 | [1] | HOSE | SUM |
| 30. | KSJ2200 | [1] | HOSE | SUM |
| 31. | KTJ1786 | [1] | HOSE | SUM |
| 32. | KHJ1932 | [1] | HOSE | SUM |
| 33. | 152904A1 | [1] | HOSE | SUM |
| 34. | 152765A1 | [1] | HOSE | SUM |
| 35. | 152988A1 | [1] | HOSE | SUM |
| 43. | 157935A1 | [1] | ELBOW | SUM |
| 45. | 150913A1 | [3] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 47. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 50. | 162826A1 | [1] | ADAPTER | SUM |
| 53. | 159497A1 | [1] | TEE | SUM |
| 56. | 157853A1 | [1] | HOSE,6.3 mm ID x 2050.00 mm | SUM2050 mm (80-11/16 in) |
| 57. | 152793A1 | [1] | HOSE ASSY. | SUM |
| 58. | 159481A1 | [1] | ADAPTER | SUM |
| 61. | 161483A1 | [1] | HOSE ASSY. | SUM450 mm (17-3/4 in) |
| 64. | 151654A1 | [2] | HYD CONNECTOR,3/4" NPT O-Ring x 3/4" NPT | SUM |
| 65. | 154503A1 | [2] | O-RING | SUM |
| 66. | KRJ4312 | [1] | HYDRAULIC HOSE,19.00 mm ID x 580.00 mm | SUM |
| 72. | 164238A1 | [1] | HOSE ASSY. | SUM3800 mm (149-5/8 in) |
| 98. | 152763A1 | [1] | HOSE ASSY. | SUM |
| 108. | KAJ2241 | [1] | HYDRAULIC HOSE,12.70 mm ID x 1300.00 mm | SUM |
| 111. | 156554A1 | [1] | ELBOW | SUM |
| 113. | KHJ1772 | [1] | HOSE | SUM |
| 119. | KUJ0273 | [1] | BRACKET | SUM |
| 120. | KUJ0274 | [2] | BRACKET | SUM |
| 121. | 159034A1 | [3] | CLAMP | SUM |
| 122. | 159037A1 | [2] | MOUNTING CLIP | SUM |
| 123. | 159378A1 | [1] | GROMMET | SUM |
| 124. | 152966A1 | [1] | GROMMET | SUM |
| 125. | 166052A1 | [6] | BOLT | SUM Superseded by part number: 11106231 |
| 127. | 150071A1 | [1] | MOUNTING CLIP | SUM |
| 129. | 150860A1 | [2] | COLLAR | SUM |
| 130. | 145N006S008R | [2] | SCREW,Pan Hd, M6 x 8mm, Cl 10.9 | SUM |
