纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-027-00[01]) - HYDRAULIC CIRCUIT - PILOT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
460 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 16. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 17. | 154475A1 | [1] | O-RING | SUM |
| 27. | KHJ1247 | [1] | HYDRAULIC HOSE | SUM |
| 28. | KHJ1248 | [1] | HYDRAULIC HOSE | SUM |
| 29. | KHJ1931 | [1] | HOSE | SUM |
| 32. | KHJ1932 | [1] | HOSE | SUM |
| 33. | 152904A1 | [1] | HOSE | SUM |
| 36. | 162554A1 | [1] | FITTING | SUM |
| 37. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 38. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 40. | 159497A1 | [1] | TEE | SUM |
| 42. | 157854A1 | [1] | HOSE,4mm ID x 750mm L | SUM |
| 45. | 150913A1 | [3] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 49. | 163814A1 | [2] | ELBOW | SUM |
| 72. | 164238A1 | [1] | HOSE ASSY. | SUM3800 mm (149-5/8 in) |
| 77. | KUJ0321 | [1] | MANIFOLD VALVE | SUM |
| 78. | 152718A1 | [2] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 79. | KTJ2121 | [1] | BRACKET | SUM |
| 81. | 152128A1 | [3] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 87. | 159002A1 | [2] | PLUG | SUM |
| 90. | 157969A1 | [1] | HOSE | SUM2600 mm (102-3/8 in) |
| 91. | 167649A1 | [1] | HOSE | SUM |
| 92. | KMJ1989 | [1] | HOSE | SUM |
| 93. | KBJ2224 | [1] | HOSE | SUM |
| 94. | 159011A1 | [1] | HOSE ASSY. | SUM1250 mm (49-1/4 in) |
| 95. | 161491A1 | [1] | HOSE | SUM |
| 96. | 161658A1 | [1] | HOSE ASSY. | SUM |
| 97. | KHJ1608 | [1] | HOSE | SUM |
| 98. | 152763A1 | [1] | HOSE ASSY. | SUM |
| 108. | KAJ2241 | [1] | HYDRAULIC HOSE,12.70 mm ID x 1300.00 mm | SUM |
| 109. | 151650A1 | [1] | HYD CONNECTOR,1/2" NPT O-Ring x 1/2" NPT | SUM |
| 110. | 154487A1 | [1] | O-RING | SUM |
| 113. | KHJ1772 | [1] | HOSE | SUM |
| 114. | 153603A1 | [1] | ADAPTER | SUM |
| 115. | 151552A1 | [1] | FILTER | SUM |
| 116. | 152899A1 | [1] | HYD CONNECTOR | SUM |
| 126. | 166350A1 | [12] | BOLT | SUM |
| 127. | 150071A1 | [1] | MOUNTING CLIP | SUM |
| 128. | 159025A1 | [1] | CLAMP | SUM |
