纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-033-00[01]) - HYDRAULIC CIRCUIT - TRAVEL MOTOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
505 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUJ0047 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1840.00 mm | SUM |
| 2. | 150124A1 | [4] | FLANGE | SUM |
| 3. | 862-14040 | [8] | HEX SOC SCREW,M14 x 40mm, Cl 12.9 | CAS |
| 4. | 164450A1 | [2] | O-RING | SUM |
| 5. | KUJ0048 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1840.00 mm | SUM |
| 9. | KUJ0055 | [1] | MANIFOLD VALVE | SUM |
| 10. | 828-14110 | [4] | BOLT,Hex, M14 x 2 x 110mm, Cl 10.9 | CASM14 x 110 |
| 12. | KUJ0212 | [1] | SHEET | SUM |
| 13. | KUJ0211 | [2] | HOSE CLAMP | SUM |
| 14. | KUJ0036 | [2] | SPACER | SUM |
| 15. | 827-10090 | [2] | BOLT,Hex, M10 x 1.5 x 90mm, Cl 10.9 | CASM10 x 90; 10,9 Superseded by part number: 828-10090 |
| 16. | 150409A1 | [2] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 17. | KUJ0214 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1850.00 mm | SUM |
| 21. | KUJ0050 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1850.00 mm | SUM |
| 28. | 152888A1 | [1] | PLATE, SPACER | SUMPLATE,SPACER |
| 29. | KUJ0213 | [2] | HOSE CLAMP | SUM |
