| 1. | KUJ0224 | [1] | HYDRAULIC HOSE,31.80 mm ID x 2000.00 mm | SUM |
| 2. | KUJ0225 | [1] | HYDRAULIC HOSE,31.80 mm ID x 2100.00 mm | SUM |
| 3. | 150124A1 | [8] | FLANGE | SUM |
| 4. | 862-14040 | [8] | HEX SOC SCREW,M14 x 40mm, Cl 12.9 | CAS |
| 5. | 164450A1 | [2] | O-RING | SUM |
| 6. | 102R014Y040R | [8] | BOLT | SUMM14 x 40 |
| 8. | 152888A1 | [1] | PLATE, SPACER | SUMPLATE,SPACER |
| 9. | KUJ0213 | [2] | HOSE CLAMP | SUM |
| 10. | KUJ0036 | [2] | SPACER | SUM |
| 11. | 827-10090 | [2] | BOLT,Hex, M10 x 1.5 x 90mm, Cl 10.9 | CASM10 x 90; 10,9 Superseded by part number: 828-10090 |
| 12. | 150409A1 | [2] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 13. | KUJ0058 | [1] | MANIFOLD VALVE | SUM |
| 14. | 102R014Y025R | [4] | BOLT | SUMM14 X 25 |
| 15. | 150418A1 | [4] | WASHER | SUM |
| 16. | KUJ0057 | [1] | BRACKET | SUM |
| 17. | 152718A1 | [4] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 18. | KUJ0218 | [1] | HYDRAULIC HOSE,25.40 mm ID x 730.00 mm | SUM |
| 19. | KUJ0062 | [1] | HYDRAULIC HOSE,25.40 mm ID x 700.00 mm | SUM |
| 20. | KUJ0219 | [1] | HYDRAULIC HOSE,25.40 mm ID x 1520.00 mm | SUM |
| 21. | KUJ0220 | [1] | HYDRAULIC HOSE,25.40 mm ID x 1550.00 mm | SUM |
| 22. | 153459A1 | [8] | FLANGE | SUM Superseded by part number: 86980728 |
| 23. | 862-10030 | [16] | HEX SOC SCREW,M10 x 30mm, Cl 12.9 | CAS Superseded by part number: 87016471 |
| 24. | 155211A1 | [4] | O-RING | SUM Superseded by part number: 86529541 |
| 25. | 153458A1 | [8] | FLANGE | SUM Superseded by part number: 71404407 |
| 27. | 155210A1 | [4] | O-RING | SUM |
| 28. | KUJ0221 | [1] | BRACKET | SUM |
| 29. | 627-12035 | [2] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 30. | 150811A1 | [2] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 32. | 152987A1 | [2] | COLLAR | SUM |
| 33. | 152895A1 | [2] | SPACER | SUM |
| 34. | 814-10100 | [2] | BOLT,Hex, M10 x 1.5 x 100mm, Cl 8.8 | CASM10 x 100; 10.9 Superseded by part number: 120075 |
| 36. | 162R010VR | [2] | NUT | SUM Superseded by part number: 86500689 |
| 37. | KUJ0223 | [1] | TUBE ASSY.,52.9 mm ID x 60.5 mm OD | SUM |
| 38. | 862-12035 | [4] | HEX SOC SCREW,M12 x 35mm, Cl 12.9 | SUM |
| 39. | 154681A1 | [1] | O-RING | SUM |
| 40. | 157581A1 | [2] | ELBOW,90º, 1" O-Ring x 1" | SUM |
| 41. | 154523A1 | [2] | O-RING | SUM |
| 42. | KUJ0222 | [2] | HYDRAULIC HOSE,25.40 mm ID x 650.00 mm | SUM |
| 43. | 157587A1 | [2] | ELBOW | SUM |
