| 1. |
87544049
|
[1] |
SUPPORT
|
ZED
|
| 2. |
84817387
|
[1] |
SHAFT
|
ZED
|
| 3. |
84057311
|
[2] |
BUSHING,25mm ID x 28mm OD x 20mm L
|
ZED
|
| 4. |
9812123
|
[1] |
BUSHING,8.5mm ID x 16mm OD x 7mm L
|
ZED
|
| 5. |
647695
|
[1] |
PIN,7.94mm OD
|
NH
|
| 6. |
84607524
|
[1] |
BUSHING,10.5mm ID x 16mm OD x 17.5mm L
|
ZED
|
| 7. |
84819180
|
[1] |
LEVER
|
ZED
|
| 8. |
NLS
|
[4] |
NO LONGER SERVICED
|
BAS
|
| 9. |
87539561
|
[1] |
IDLER WHEEL
|
ZED
, Serial Range: -C939
|
| 9. |
84488484
|
[1] |
PLOW DISC
|
ZED
, Start Serial: D940
|
| 10. |
431485
|
[2] |
UNIVERSAL JOINT
|
ZED
|
| 11. |
84021291
|
[2] |
DISC
|
ZED
|
| 12. |
9838303
|
[1] |
GEAR
|
ZED
|
| 13. |
84023349
|
[1] |
DECAL
|
ZED
|
| 14. |
84817360
|
[1] |
SUPPORT
|
ZED
|
| 15. |
84058905
|
[1] |
SECTOR
|
ZED
TOOTHED SECTOR
|
| 16. |
84032061
|
[1] |
PLATE
|
ZED
|
| 17. |
9838296
|
[1] |
HANDLE
|
ZED
|
| 18. |
9838295
|
[1] |
BOLT
|
ZED
|
| 19. |
84014935
|
[1] |
THREADED TIE-ROD
|
ZED
|
| 20. |
9838278
|
[1] |
SPRING
|
ZED
|
| 21. |
9838297
|
[1] |
CLEVIS,M12
|
ZED
|
| 22. |
9838300
|
[1] |
ROD
|
ZED
|
| 23. |
84031235
|
[1] |
PLATE
|
ZED
|
| 24. |
84031241
|
[1] |
SUPPORT
|
ZED
|
| 25. |
84031601
|
[1] |
SHIELD
|
ZED
|
| 26. |
86000441
|
[2] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 27. |
385188
|
[3] |
SHIM,26mm ID x 34mm OD x 0.5mm Thk
|
PA
16 MM, Serial Range: -C939
|
| 28. |
9839230
|
[1] |
WASHER
|
ZED
Superseded by part number: 27317
|
| 29. |
338206
|
[3] |
WASHER,26mm ID x 35mm OD x 2mm Thk
|
ZED
|
| 30. |
43128
|
[8] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 31. |
86624184
|
[1] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 32. |
9706690
|
[14] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 33. |
322358
|
[14] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 34. |
43127
|
[1] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 35. |
9706704
|
[1] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 36. |
378244
|
[2] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 37. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 38. |
100016
|
[5] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 39. |
370002
|
[1] |
CIRCLIP,M25, External
|
NH
|
| 40. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 41. |
9706755
|
[2] |
NUT,M6, Cl 8
|
NH
Superseded by part number: 86500688
|
| 42. |
86508568
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 43. |
120104
|
[5] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 44. |
120044
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 45. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 46. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 47. |
9838279
|
[3] |
BELLEVILLE WASHER
|
ZED
|
| 48. |
412126
|
[1] |
NUT,M12 x 1.75
|
ZED
|
| 49. |
328754
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 50. |
338949
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 51. |
323238
|
[1] |
THIN NUT,Hex, M12, 1.75mm Pitch, Cl 05
|
ZED
|
| 52. |
130004
|
[1] |
COTTER PIN,2.9mm OD x 31.4mm OAL
|
WIN
|
| 53. |
378245
|
[2] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 54. |
87730773
|
[1] |
CAP
|
ZED
|
| 55. |
84032097
|
[1] |
CHAIN
|
ZED
|
| 56. |
9838937
|
[1] |
SPRING
|
ZED
|
| 57. |
9838938
|
[1] |
BALE COUNTER
|
ZED
, Serial Range: -C899 Superseded by part number: 86608973
|
| 57. |
86608973
|
[1] |
BALE COUNTER
|
NH
, Start Serial: D900
|
| 58. |
130003
|
[1] |
COTTER PIN,3mm OD x 30mm OAL
|
ZED
|
| 59. |
87395156
|
[2] |
REGULATING SYSTEM
|
ZED
|
| 60. |
87395158
|
[1] |
GUARD
|
ZED
|
| 61. |
87395159
|
[1] |
GUARD
|
ZED
|
| 62. |
84475774
|
[4] |
SHIM
|
ZED
, Start Serial: D940
|
