纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-047-01[01]) - HYDRAULIC CIRCUIT - PILOT CONTROL LINES WITH LOAD HOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
447 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 34. | 150913A1 | [4] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 35. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 36. | 161841A1 | [1] | HYD CONNECTOR | SUM |
| 37. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 40. | 164941A1 | [1] | HYDRAULIC HOSE,6.40 mm ID x 4500.00 mm | SUM |
| 41. | MPJ5370 | [1] | HOSE | SUM |
| 44. | KAJ3524 | [1] | HYDRAULIC HOSE | SUM |
| 45. | 159019A1 | [1] | HOSE ASSY. | SUM900 mm (35-1/2 in) |
| 54. | KRJ5903 | [1] | MANIFOLD | SUM |
| 55. | 827-8100 | [4] | BOLT,Hex, M8 x 1.25 x 100mm, Cl 10.9 | CAS Superseded by part number: 86512165 |
| 56. | 153081A1 | [4] | WASHER | SUM |
| 60. | KHJ1394 | [3] | CLAMP | SUM |
| 63. | 627-8012 | [6] | BOLT,Hex, M8 x 1.25 x 12mm, Cl 10.9, Full Thd | SUM Superseded by part number: 43231 |
| 65. | 150860A1 | [1] | COLLAR | SUM |
| 66. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
| 67. | 150071A1 | [1] | MOUNTING CLIP | SUM |
| 96. | 157969A1 | [1] | HOSE | SUM |
| 107. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 108. | 154475A1 | [1] | O-RING | SUM |
| 117. | KRJ4763 | [1] | HOSE | SUM |
| 161. | KRA1395 | [1] | SEAL, RUBBER | SUMRUBBER SEAL |
| 166. | 152753A1 | [1] | HOSE,95.00 mm ID x 1100.00 mm | SUM |
| 168. | KUJ0304 | [1] | MANIFOLD | SUM |
| 169. | 814-10100 | [2] | BOLT,Hex, M10 x 1.5 x 100mm, Cl 8.8 | CAS Superseded by part number: 120075 |
| 170. | 150409A1 | [2] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 171. | 150916A1 | [6] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 174. | 157972A1 | [1] | HOSE ASSY. | SUM |
| 175. | 159063A1 | [1] | HOSE | SUM |
| 176. | KRH1445 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHH12760 |
| 177. | 150067A1 | [1] | MOUNTING CLIP | SUM150 mm (6 in) |
| 179. | KRH1434 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHH12760 |
