纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-047-02[01]) - HYDRAULIC CRICUIT - PILOT CONTROL LINES WITHOUT LOAD HOLD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
322 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 40. | 164941A1 | [1] | HYDRAULIC HOSE,6.40 mm ID x 4500.00 mm | SUM |
| 42. | MPJ5370 | [1] | HOSE | SUM |
| 48. | 156554A1 | [4] | ELBOW | SUM |
| 49. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 153. | KHJ1249 | [2] | CLAMP | SUM |
| 154. | 166350A1 | [4] | BOLT | SUM |
| 155. | 159040A1 | [1] | CLAMP | SUM |
| 157. | 159039A1 | [1] | CLAMP | SUM |
| 161. | KHJ1250 | [2] | SEAL, RUBBER | SUMRUBBER SEAL |
| 162. | 159028A1 | [1] | RUBBER BLOCK | SUM |
| 163. | KTA1036 | [1] | SEAL, RUBBER | SUMRUBBER SEAL |
| 164. | KRA1395 | [1] | SEAL, RUBBER | SUMRUBBER SEAL |
| 165. | 150071A1 | [1] | MOUNTING CLIP | SUM |
