凯斯零件查询(LB333P) - BIG RECTANGULAR BALER 'PACKER CUTTER' (9/08-12/12) (15.10[01]) - NEEDLES - CLEANING KIT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
600 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84801637
|
[6] |
SPRING
|
ZED
|
| 2. |
84801091
|
[1] |
SUPPORT
|
ZED
|
| 2. |
84801087
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84801089
|
[2] |
ANGLE
|
ZED
|
| 4. |
43127
|
[6] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 5. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 6. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 7. |
350240
|
[6] |
WASHER,9mm ID x 20mm OD x 4mm Thk
|
WIN
|
| 8. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 10. |
43139
|
[4] |
BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
Superseded by part number: 11106231
|
