| 4. | KUJ0112 | [2] | PIPE CLAMP | SUM |
| 5. | 827-12090 | [2] | BOLT,Hex, M12 x 1.75 x 90mm, Cl 10.9 | CASM12 x 90; 10.9 Superseded by part number: 412605 |
| 6. | 150811A1 | [4] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 7. | 829-1412 | [2] | NUT,M12, Cl 10 | CAS Superseded by part number: 337475 |
| 8. | KUJ0113 | [1] | BRACKET | SUM |
| 9. | 627-12040 | [2] | BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 337563 |
| 11. | 168211A1 | [1] | O-RING | SUM |
| 12. | KTJ0169 | [2] | FLANGE | SUM |
| 13. | 862-16050 | [4] | HEX SOC SCREW,M16 x 50mm, Cl 12.9 | CASM16 x 50; 12.9 Superseded by part number: 9817243 |
| 14. | KUJ0261 | [1] | HYDRAULIC HOSE,38.10 mm ID x 1040.00 mm | SUM |
| 15. | 164450A1 | [2] | O-RING | SUM |
| 16. | 150124A1 | [4] | FLANGE | SUM |
| 17. | 862-14040 | [8] | HEX SOC SCREW,M14 x 40mm, Cl 12.9 | CAS |
| 20. | KUJ0392 | [1] | BRACKET | SUM |
| 21. | 165929A1 | [4] | BOLT,Sems, M16 | SUM |
| 53. | 157856A1 | [2] | CLAMP BRACKET | SUM |
| 54. | 862-10030 | [4] | HEX SOC SCREW,M10 x 30mm, Cl 12.9 | CAS Superseded by part number: 87016471 |
| 55. | 154721A1 | [1] | O-RING,99.4mm ID x 3.1mm Width | SUM |
| 56. | KUJ0155 | [1] | COUPLING FLANGE | SUM |
| 57. | 627-16050 | [4] | BOLT,Hex, M16 x 2 x 50mm, Cl 10.9, Full Thd | CAS Superseded by part number: 412398 |
| 64. | KUJ0253 | [1] | BRACKET | SUM |
| 65. | KUJ0252 | [4] | HOSE CLAMP | SUM |
| 66. | KUJ0034 | [2] | SHEET | SUM |
| 67. | KUJ0036 | [4] | SPACER | SUM |
| 68. | 814-10100 | [2] | BOLT,Hex, M10 x 1.5 x 100mm, Cl 8.8 | CAS Superseded by part number: 120075 |
| 69. | 162R010VR | [2] | NUT | SUMM10; 10.9 Superseded by part number: 86500689 |
| 70. | 150409A1 | [6] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 71. | 627-12035 | [2] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 73. | 150933A1 | [1] | ELBOW | SUM |
| 74. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 75. | KHJ0994 | [1] | ADAPTER | SUM |
| 77. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 79. | 161483A1 | [1] | HOSE ASSY. | SUM |
| 80. | 159002A1 | [1] | PLUG | SUM |
| 86. | KTJ1786 | [1] | HOSE | SUM |
| 87. | 164236A1 | [1] | HOSE ASSY. | SUM1000 mm (39-3/8 in)1 |
| 88. | 159019A1 | [1] | HOSE ASSY. | SUM900 mm (35-1/2 in) |
| 90. | KHJ2255 | [1] | HOSE | SUM |
| 91. | 156554A1 | [2] | ELBOW | SUM |
