| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUB0157 | [1] | ARM | SUM |
| 2. | 153630A1 | [2] | LUBE NIPPLE | SUM |
| 4. | KUB0175 | [2] | PLATE | SUM |
| 5. | 166348A1 | [4] | BOLT | SUM |
| 6. | KUB0163 | [2] | PLATE | SUM |
| 7. | 105R020Y050R | [4] | BOLT | SUM |
| 11. | KUB0155 | [1] | HYDRAULIC CYLINDER | SUM |
| 23. | 814-10100 | [1] | BOLT,Hex, M10 x 1.5 x 100mm, Cl 8.8 | CAS Superseded by part number: 120075 |
| 24. | 829-1410 | [2] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 43. | KUB0172 | [1] | BRACKET | SUM |
| 46. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 47. | 154475A1 | [1] | O-RING | SUM |
| 48. | KUJ0291 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1500.00 mm | SUM |
| 76. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 164. | 159497A1 | [1] | TEE | SUM |
| 165. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 166. | 160439A1 | [1] | HOSE ASSY. | SUM |
| 170. | 162554A1 | [1] | FITTING | SUM |
| 178. | 157851A1 | [1] | HOSE | SUM2850 mm (112-1/4 in) |
| 179. | 158186A1 | [1] | PRESSURE RELIEF VALVE | SUM Superseded by part number: KHJ26180 |
| 180. | 158183A1 | [1] | ELEC CONNECTOR,Male | SUM |
| 182. | 150913A1 | [2] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 195. | 150860A1 | [1] | COLLAR | SUM |
| 196. | 840-168 | [1] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
| 197. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm (10 in) |
| 198. | 158962A1 | [1] | CLIP | SUM |
| 199. | 167518A1 | [1] | BOLT | SUM |
