纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-077-08[01]) - COUNTERWEIGHT REMOVAL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
1007 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 56. | KHJ1810 | [1] | VALVE | SUM Superseded by part number: KHJ17390 |
| 57. | 102R005Y045R | [2] | BOLT | SUM |
| 58. | 892-11005 | [2] | LOCK WASHER,M5 | CAS Superseded by part number: 10569179 |
| 59. | 895-11005 | [2] | WASHER,M5 x 10 x 1 | CAS Superseded by part number: 86625261 |
| 60. | KUJ0300 | [1] | BRACKET | SUM |
| 61. | 167182A1 | [2] | BOLT,Sems, M8 x 25mm | SUM |
| 62. | 150916A1 | [1] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 63. | 154475A1 | [1] | O-RING | SUM |
| 64. | KHJ2284 | [1] | HYDRAULIC HOSE,9.50 mm ID x 500.00 mm | SUM |
| 65. | KUJ0298 | [1] | MANIFOLD VALVE | SUM |
| 66. | 166052A1 | [4] | BOLT | SUM Superseded by part number: 11106231 |
| 67. | KUJ0288 | [1] | SOLENOID VALVE | SUM |
| 68. | 153105A1 | [1] | PLUG | SUM |
| 72. | 164107A1 | [1] | TEE,3/8" ORB x 3/8" - 19 NPT x 3/8" - 19 NPT | SUM |
| 78. | KUB0181 | [1] | BRACKET | SUM |
| 79. | 627-12035 | [2] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 80. | 150811A1 | [2] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 82. | KHJ1539 | [1] | HYDRAULIC HOSE,9.52 mm ID x 500.00 mm | SUM |
| 100. | KUJ0289 | [1] | PRESSURE RELIEF VALVE | SUM |
| 101. | 827-8060 | [2] | BOLT,Hex, M8 x 1.25 x 60mm, Cl 10.9 | CAS Superseded by part number: 86625005 |
| 102. | 895-11008 | [2] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
| 103. | 152128A1 | [1] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 110. | KRJ5868 | [1] | HYDRAULIC HOSE,9.50 mm ID x 1750.00 mm | SUM |
| 193. | KUR0091 | [1] | BRACKET | SUM |
