纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-077-09[01]) - COUNTERWEIGHT REMOVAL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
808 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 49. | HEJ0119 | [1] | COLLAR | SUM |
| 50. | HEJ0121 | [1] | COLLAR | SUM |
| 51. | 166351A1 | [1] | BOLT,Sems, M10 x 20mm | SUM |
| 52. | KUJ0292 | [1] | BRACKET | SUM |
| 53. | 166347A1 | [2] | BOLT,Sems, M10 x 30mm | SUM |
| 70. | 150916A1 | [2] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 71. | 154475A1 | [1] | O-RING | SUM |
| 74. | 159226A1 | [1] | ADAPTER | SUM |
| 83. | KUJ0298 | [1] | MANIFOLD VALVE | SUM |
| 84. | 166052A1 | [4] | BOLT | SUM Superseded by part number: 11106231 |
| 85. | KUJ0288 | [1] | SOLENOID VALVE | SUM |
| 86. | 153105A1 | [1] | PLUG | SUM |
| 96. | KUB0181 | [1] | BRACKET | SUM |
| 97. | 627-12035 | [2] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 98. | 150811A1 | [2] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 99. | KHJ2284 | [1] | HYDRAULIC HOSE,9.50 mm ID x 500.00 mm | SUM |
| 115. | KHJ2286 | [2] | HYDRAULIC HOSE,9.50 mm ID x 3500.00 mm | SUM |
| 123. | KHJ1819 | [2] | HYDRAULIC HOSE | SUM |
| 127. | KUB0182 | [1] | BRACKET | SUM |
| 128. | 166352A1 | [2] | BOLT | SUM |
| 129. | HEJ0122 | [4] | HOSE CLAMP | SUM |
| 130. | KUJ0293 | [2] | CLAMP | SUM |
| 131. | 166346A1 | [2] | BOLT,Sems, M10 | SUM |
| 135. | 150409A1 | [1] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 136. | 829-1410 | [1] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 166. | 160439A1 | [1] | HOSE ASSY. | SUM |
| 169. | KHJ1608 | [1] | HOSE | SUM |
| 172. | 158186A1 | [1] | PRESSURE RELIEF VALVE | SUM Superseded by part number: KHJ26180 |
| 173. | 158183A1 | [1] | ELEC CONNECTOR,Male | SUM |
| 174. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 175. | 167321A1 | [1] | TEE | SUM |
| 176. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 178. | 157851A1 | [1] | HOSE | SUM2850 mm (112-1/4 in) |
