纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (08-079-02[01]) - HIGH PRESSURE HYDRAULIC PUMP - REGULATOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
640 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 88. | NSS | [1] | NOT SERVICED SEPARATELY | CONRegulator |
| 89. | 861-6060 | [4] | HEX SOC SCREW,M6 x 60mm, Cl 12.9 | SUMM6 x 60; 12.9 |
| 90. | 108R008Z050N | [2] | BOLT | SUM |
| 91. | 861-8070 | [2] | HEX SOC SCREW,M8 x 70mm, Cl 12.9 | CASM8 x 70; 12.9 |
| 92. | 861-6030 | [2] | HEX SOC SCREW,M6 x 30mm, Cl 12.9 | SUMM6 x 30; 12.9 Superseded by part number: 108R006Z030N |
| 93. | 862-6020 | [6] | HEX SOC SCREW,M6 x 20mm, Cl 12.9 | CASM6 x 20; 12.9 |
| 94. | 155496A1 | [1] | PLUG | SUM |
| 95. | LK00003 | [6] | PLUG | SUM |
| 96. | TPP0095 | [2] | VALVE SEAT | SUM |
| 97. | TPP0094 | [2] | STOP | SUM |
| 98. | 156966A1 | [2] | BALL | SUM |
| 114. | TUP0040 | [1] | SPECIAL NUT | SUM |
| 128. | 154681A1 | [1] | O-RING | SUM |
| 129. | 154447A1 | [3] | O-RING | SUM |
| 130. | 154455A1 | [8] | O-RING | SUM |
| 131. | 154463A1 | [1] | O-RING | SUM |
| 132. | 154487A1 | [1] | O-RING | SUM |
| 133. | 154499A1 | [1] | O-RING | SUM |
| 134. | 154483A1 | [2] | O-RING | SUM |
| 135. | 154491A1 | [1] | O-RING | SUM |
| 136. | 154509A1 | [1] | O-RING | SUM |
| 137. | 154471A1 | [1] | O-RING | SUM |
| 138. | 154467A1 | [11] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 139. | 154515A1 | [1] | O-RING | SUM |
| 140. | 154549A1 | [1] | O-RING | SUM |
| 141. | LA00065 | [2] | JAM NUT | SUM |
| 142. | 800-1110 | [1] | SNAP RING,M10, Ext | CAS Superseded by part number: 3991509 |
| 143. | LMM0597 | [1] | RING, SNAP | SUMSNAP RING |
| 150. | LA00759 | [1] | BOLT,Hex Skt Hd | SUM |
| 151. | TUP0041 | [1] | SET SCREW | SUM |
