神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-015) - CONTROL ASSY, ENGINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
133 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY11M00002F1 | [1] | CONTROL | KOBASSY, ENGINE |
| 1. | YN20S00002F1 | [1] | MOTOR | KOBASSY, GOVERNOR |
| . . | YN20S00002F1R | [1] | REMAN-ELECTRIC MOTOR | KOBSK135SR-1E ASN YY03-04555, SK135SRL-1E ASN LK03-01107, SK135SRLC-1E ASN YH03-02097 |
| . . | YN20S00002F1C | [1] | CORE-ELECTRIC MOTOR | KOBReturn Number |
| 2. | YY11M01009P2 | [1] | BRACKET | KOB |
| 3. | YX11M01005P1 | [1] | ROD | KOB |
| 4. | YN11M01013D1 | [1] | BALL JOINT | KOBM08x1.25x36mm Long (Left hand thread) Superseded by part number: HR37D08000G1 |
| 5. | HR37C08000G1 | [1] | BALL JOINT | KOBReplaces 2425R227D2, M08x1.25x45.5mm Long |
| 6. | YX11M01002P1 | [1] | LEVER | KOB |
| 7. | YN11M01032P1 | [1] | LEVER | KOB |
| 8. | YX11M01006P1 | [1] | ROD | KOB |
| 9. | YX11M01003P2 | [1] | CABLE | KOBCONTROL |
| 10. | 2432T4615 | [1] | LABEL | KOBDecal -- 45x45mm Red triangle |
| 11. | LP11M01014P1 | [1] | PIN | KOB |
| 12. | 2419R9D1 | [1] | COTTER PIN | KOBOD 06mm x 21.2mm Long |
| 13. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 14. | ZW16X10000 | [6] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 15. | ZS18C06016 | [2] | SCREW,Hex, M6 x 16mm | KOBM06x1.0x16mm |
| 16. | ZS28C06025 | [1] | SCREW,Hex Socket Head, M6 x 25mm | KOBM06x1.0x25mm |
| 17. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 18. | ZS18F10030 | [1] | BOLT,Hex, M10 x 30mm | KOBM10x1.25x30mm |
| 19. | ZS28C10035 | [3] | SCREW,Hex Socket Head, M10 x 35mm | KOBScrew -- M10x1.50x35mm |
| 20. | ZW26X06000 | [3] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 21. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 22. | ZW16H08000 | [2] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 23. | ZW26K10000 | [3] | LOCK WASHER | KOBLock -- ID 10 x OD 15.7 x Th 2.5mm Superseded by part number: 12581679 |
| 24. | ZN18C06005 | [2] | NUT | KOBM06x1.0mm |
| 25. | ZN18C08007 | [3] | NUT | KOBM08x1.25mm |
| 26. | 2420T7359 | [1] | NUT | KOBM08x1.25mm -- Left Hand Threads |
| 27. | ZN18F10008 | [2] | NUT | KOBM10x1.25mm |
| 28. | YR03M01293P1 | [1] | GROMMET | KOB |
| 29. | 2432R233D3 | [1] | CLIP | KOB50x16x60mm |
| 30. | ZS18F10020 | [1] | BOLT,Hex, M10 x 20mm | KOBM10x1.25x20mm |
