凯斯零件查询(LB333R) - BIG RECTANGULAR BALER 'ROTOR CUTTER' (9/08-12/12) (01.03[01]) - POWER TAKE-OFF, REAR, SHIELD Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
223 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87631659
|
[1] |
SHIELD
|
ZED
|
| 2. |
140046
|
[3] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 3. |
300389
|
[3] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 4. |
86507486
|
[2] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 5. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 6. |
9706690
|
[2] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 7. |
87603215
|
[1] |
PLATE
|
ZED
|
| 8. |
120041
|
[2] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 9. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 10. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 11. |
84135583
|
[1] |
SHIELD
|
ZED
, Start Serial: D700
|
| 15. |
84135751
|
[1] |
BUSHING
|
ZED
, Serial Range: -F708881
|
| 15. |
84388820
|
[1] |
SLEEVE,45mm ID x 60mm OD x 22.8mm L
|
ZED
, Start Serial: D882
|
| 16. |
86566989
|
[1] |
CABLE TIE,208mm L
|
ZED
CABLE STRAP, Start Serial: D882
|
