| 1. |
84154067
|
[1] |
PTO
|
ZED
(2 TO 28), Serial Range: -C947
|
| 1. |
84483320
|
[1] |
PTO
|
ZED
(2 TO 28), Start Serial: D948
|
| 2. |
87716336
|
[1] |
PIN
|
ZED
, Serial Range: -C895
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
, Start Serial: D896
|
| 3. |
87716337
|
[1] |
SPIDER
|
ZED
Superseded by part number: 87012142
|
| 6. |
87716338
|
[1] |
PTO SHAFT
|
ZED
, Serial Range: -C895
|
| 7. |
84976975
|
[1] |
ROLL PIN
|
PLO
, Serial Range: -C895 Superseded by part number: 14610770
|
| 8. |
87716339
|
[1] |
YOKE
|
ZED
, Serial Range: -C895
|
| 9. |
87716340
|
[1] |
YOKE
|
ZED
(10, 11) Superseded by part number: 47411643
|
| 10. |
87587210
|
[1] |
KIT
|
ZED
|
| 12. |
84036369
|
[1] |
LUBE NIPPLE
|
ZED
, Serial Range: -C895
|
| 13. |
87716341
|
[1] |
PROTECTION CAP
|
ZED
|
| 14. |
87716342
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C895 Superseded by part number: 87517831
|
| 14. |
87517831
|
[1] |
BEARING COVER,89.4 mm ID x 132 mm OD x 12 mm
|
BEL
, Start Serial: D896
|
| 15. |
87587200
|
[6] |
SELF-TAP SCREW
|
ZED
|
| 16. |
87716343
|
[1] |
PROTECTING COVER
|
ZED
, Serial Range: -C947
|
| 16. |
84555362
|
[1] |
SHIELD
|
ZED
, Start Serial: D948
|
| 17. |
87716344
|
[1] |
PROTECTING COVER
|
ZED
, Serial Range: -C947
|
| 17. |
84555363
|
[1] |
SHIELD
|
ZED
, Start Serial: D948
|
| 18. |
87716345
|
[1] |
SHIELD
|
ZED
|
| 19. |
87716346
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C895 Superseded by part number: 86979196
|
| 19. |
86979196
|
[1] |
BEARING,86mm ID x 132mm OD x 12mm H
|
PA
, Start Serial: D896
|
| 20. |
87716347
|
[2] |
CHAIN,400mm L
|
ZED
Superseded by part number: 87685054
|
| 21. |
87716348
|
[1] |
DANGER DECAL
|
ZED
|
| 22. |
84078329
|
[1] |
DECAL
|
ZED
Superseded by part number: 47475712
|
| 23. |
87716350
|
[1] |
FRONT PTO ASSY
|
ZED
(2, 12, 14, 16, 18, 20, 21, 26, 27), Serial Range: -C895
|
| 23. |
84517315
|
[1] |
SHIELD
|
ZED
(2, 12, 14, 16, 18, 20, 21, 26, 27), Serial Range: -F896947
|
| 23. |
84555364
|
[1] |
SHIELD
|
ZED
(2, 12, 14, 16, 18, 20, 21, 26, 27), Start Serial: D948
|
| 24. |
87716351
|
[1] |
REAR PTO ASSY
|
ZED
(3 TO 11, 13, 17, 19, 22, 28), Serial Range: -C895
|
| 24. |
84517316
|
[1] |
SHIELD
|
ZED
(3 TO 11, 13, 17, 19, 22, 28), Serial Range: -F896947
|
| 24. |
84555365
|
[1] |
SHIELD
|
ZED
(3 TO 11, 13, 17, 19, 22, 28), Start Serial: D948
|
| 25. |
87716352
|
[1] |
KIT
|
ZED
(13 TO 20), Serial Range: -C895
|
| 25. |
84517317
|
[1] |
SHIELD
|
ZED
(13 TO 20), Serial Range: -F896947
|
| 25. |
84555366
|
[1] |
SHIELD
|
ZED
(14 TO 20), Start Serial: D948
|
| 26. |
84157905
|
[1] |
ROLL PIN
|
ZED
, Serial Range: -C895 Superseded by part number: 763847
|
| 27. |
84157906
|
[1] |
TUBE
|
ZED
, Serial Range: -C895
|
| 28. |
84157907
|
[1] |
DECAL
|
ZED
Superseded by part number: 87685057
|
