纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-017-00[01]) - COWLING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
918 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 152718A1 | [2] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 11. | 166352A1 | [12] | BOLT | SUM |
| 12. | KUN0272 | [1] | PLATE | SUM |
| 57. | KUN0356 | [1] | COVER | SUM |
| 60. | 862-12030 | [2] | HEX SOC SCREW,M12 x 30mm, Cl 12.9 | SUM |
| 61. | 863-12045 | [2] | HEX SOC SCREW,M12 x 45mm, Cl 12.9 | CASM12 x 45; 12.9 Superseded by part number: 86312045 |
| 62. | 150811A1 | [4] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 63. | KUN0274 | [1] | DOOR | SUM |
| 64. | 162447A1 | [2] | HINGE | SUM |
| 73. | 159101A1 | [1] | STAY | SUM |
| 74. | 153181A1 | [1] | COTTER PIN | SUM |
| 75. | KUN0235 | [1] | COVER | SUM |
| 82. | KUN0399 | [2] | BRACKET | SUM |
| 83. | 627-8030 | [4] | BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43235 |
| 84. | 895-11008 | [4] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
| 85. | 183-108VR | [4] | SPRING WASHER | SUMW8 |
| 86. | KUN0150 | [2] | CUPEL | SUM |
| 87. | 145S008S025R | [4] | SCREW,Flush Hd, M8 x 25mm | SUMM8 x 25 |
| 88. | KBN0761 | [1] | PLATE | SUM |
| 89. | KUN0149 | [2] | CUPEL | SUM |
| 90. | 145S008S020R | [4] | SCREW,Flush Hd, M8 x 20mm | SUMM8 x 20 |
| 91. | KBN0762 | [1] | PLATE | SUM |
| 96. | KUN0236 | [1] | DOOR | SUM |
| 97. | 162434A1 | [1] | LOCK | SUM |
| 132. | KUN0161B1 | [1] | STAY | SUM |
| 137. | KUN0265B1 | [1] | STAY | SUM |
| 146. | KUN0325 | [1] | INSULATOR | SUM |
| 147. | KUN0326 | [1] | INSULATOR | SUM |
| 157. | KUN0336 | [1] | INSULATOR | SUM |
| 158. | KUN0337 | [1] | INSULATOR | SUM |
| 159. | KUN0338 | [1] | INSULATOR | SUM |
| 160. | KUN0339 | [1] | INSULATOR | SUM |
| 161. | KUN0340 | [1] | INSULATOR | SUM |
| 162. | KUN0341 | [1] | INSULATOR | SUM |
| 164. | KUN0343 | [1] | INSULATOR | SUM |
| 166. | KUN0347 | [1] | SEAL | SUM |
| 167. | KUN0348 | [1] | SEAL | SUM |
| 168. | KUN0078 | [1] | INSULATOR | SUM |
| 170. | KUN0080 | [1] | INSULATOR | SUM |
| 171. | KUN0081 | [1] | INSULATOR | SUM |
| 172. | KUN0083 | [1] | INSULATOR | SUM |
| 173. | KUN0087 | [1] | SEAL | SUM |
| 174. | KUN0344 | [2] | INSULATOR | SUM |
| 175. | KUN0345 | [2] | INSULATOR | SUM |
| 177. | KUN0361 | [1] | INSULATOR | SUM |
| 183. | KUN0374 | [2] | INSULATOR | SUM |
| 191. | KUN0306 | [1] | ENGINE HOOD | SUM |
| 192. | 151104A1 | [3] | HINGE | SUM |
| 196. | KUN0308 | [1] | HOOD ASSY. | SUM |
| 210. | KUN0324 | [1] | HOOD ASSY. | SUM Superseded by part number: KUN0415 |
| 222. | 829-1408 | [8] | NUT,Hex, M8 x 1.25, Cl 10.9 | CAS Superseded by part number: 43362, 87778059 |
| 246. | KUN0313 | [1] | HOOD ASSY. | SUM Superseded by part number: KUN0414 |
