纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-029-00[01]) - COWLING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
634 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 10. | 152718A1 | [6] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 28. | KUN0407 | [1] | COVER | SUM |
| 29. | 166352A1 | [3] | BOLT | SUM |
| 30. | KUN0406 | [1] | COVER | SUM |
| 32. | KHR3084 | [1] | GASKET | SUM |
| 33. | KUN0301 | [1] | COVER | SUM |
| 41. | KUN0290 | [1] | FRAME | SUM |
| 71. | KUN0183 | [2] | BRACKET | SUM |
| 92. | KUN0253 | [1] | STAY | SUM |
| 93. | 167647A1 | [1] | SPLIT PIN/SAFETY PIN | SUM |
| 148. | KUN0327 | [1] | INSULATOR | SUM |
| 149. | KUN0328 | [1] | INSULATOR | SUM |
| 150. | KUN0329 | [1] | INSULATOR | SUM |
| 165. | KUN0346 | [1] | SEAL | SUM |
| 172. | KUN0083 | [1] | INSULATOR | SUM |
| 173. | KUN0087 | [1] | SEAL | SUM |
| 174. | KUN0344 | [2] | INSULATOR | SUM |
| 175. | KUN0345 | [2] | INSULATOR | SUM |
| 176. | KUN0360 | [1] | INSULATOR | SUM |
| 178A. | KTN1331 | [1] | INSULATOR | SUM |
| 178B. | KSN1300 | [1] | FOAM INSULATION | SUM |
| 179. | KUN0363 | [1] | INSULATOR | SUM |
| 181. | KUN0365 | [1] | INSULATOR | SUM |
| 182. | KUN0366 | [1] | INSULATOR | SUM |
| 185. | KUN0376 | [1] | INSULATOR | SUM |
| 186. | KUN0377 | [1] | INSULATOR | SUM |
| 187. | KUN0369 | [2] | SEAL | SUM |
| 188. | 895-11008 | [4] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
| 189. | 827-8045 | [4] | BOLT,Hex, M8 x 1.25 x 45mm, Cl 10.9 | CAS Superseded by part number: 16044131 |
| 190. | KHH0358 | [4] | RETAINER | SUM |
| 205. | 159119A1 | [1] | STAY | SUM |
| 208. | KUN0311 | [1] | HOOD ASSY. | SUM Superseded by part number: KUN0413 |
| 210. | KUN0324 | [1] | HOOD ASSY. | SUM Superseded by part number: KUN0415 |
| 212. | KUN0314 | [1] | HOOD ASSY. | SUM |
| 214. | KUN0392 | [1] | HOOD ASSY. | SUM Superseded by part number: KUN0417 |
| 215. | 627-12035 | [4] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 216. | 162R012VR | [4] | NUT | SUMM12 |
| 217. | 150811A1 | [4] | WASHER | SUMM12 Superseded by part number: 86625255 |
| 218. | 151356A1 | [1] | LOCK ASSY | SUM |
| 219. | 627-8030 | [4] | BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43235 |
| 220. | 183-108VR | [4] | SPRING WASHER | SUMW8 |
| 222. | 829-1408 | [2] | NUT,Hex, M8 x 1.25, Cl 10.9 | CAS Superseded by part number: 43362, 87778059 |
| 223. | 150785A1 | [1] | STOP LOCK | SUM |
| 224. | 151361A1 | [1] | HANDLE | SUM |
| 233. | KUN0323 | [2] | BRACKET | SUM |
| 235. | KUN0321 | [2] | BRACKET | SUM |
| 237. | KUN0391 | [1] | STAY | SUM |
| 240. | KUN0397 | [1] | TORSION SPRING | SUM |
| 244. | KUN0400 | [1] | HOOD ASSY. | SUM |
