纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-035-00[01]) - HAND CONTROL VALVE - OPERATORS COMPARTMENT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
752 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 26. | KHJ1651 | [2] | BRACKET | SUM |
| 27. | KHN2132 | [4] | BOLT,Hex Flg Hd, M6 x 16 | SUM |
| 28. | KTJ2035 | [2] | CONTROL BLOCK | SUM |
| 29. | 862-6025 | [8] | HEX SOC SCREW,M6 x 25mm, Cl 12.9 | SUM |
| 30. | 892-11006 | [8] | LOCK WASHER,M6 | CAS Superseded by part number: 86517328 |
| 31. | KHJ1556 | [1] | KNOB | SUM |
| 32. | KHJ1557 | [1] | GRIP | SUM |
| 33. | 151154A1 | [2] | JAM NUT | SUM |
| 34. | 151302A1 | [2] | CAP | SUM |
| 35. | KHJ1644 | [2] | HOSE PROTECTION | SUM |
| 36. | KHJ1645 | [2] | BRACKET | SUM |
| 37. | 166345A1 | [4] | BOLT | SUM Superseded by part number: 105R008Y016R |
